Twin-screw plastic Extruder
- 100 Set / Sets per Month
- Qingdao Port
- T/T
Product Details
| Condition: | New | Application: | Other | Plastic Processed: | PVC |
| Screw Design: | Double-screw | Automatic Grade: | Automatic | Place of Origin: | Shandong, China |
| Brand Name: | HUAYA | Model Number: | SJSZ | Voltage: | 220V/380V |
| Power(W): | 15-110kw | Dimension(L*W*H): | CAPACITY | Weight: | CAPACITY |
| Certification: | CE ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
The most professional sales team
7X24 hours best service
The most professional technicists provide the best after-sale service
SJZS series conical twin screw extruder is one kind of specifical equipment that is suitable for PVC powder extrusion molding. If equipped with different molds and auxiliaries , it can produce all kinds of PVC plastic pipe profile ,board ,sheet , rod and pelleting .The screw adopts oil cooling system . The barrel adopts special air-cooling system .
Main technical parameters
Model | SJSZ45/90 | SJSZ51/105 | SJSZ55/110 | SJSZ65/132 | SJSZ80/156 | SJSZ92/188 |
Screw diameter(mm) | 49-90 | 51-105 | 55-110 | 65-132 | 80-156 | 92-188 |
Screw speed(rpm) | 45 | 40 | 38 | 38 | 37 | 36 |
Screw torque (N.m) | 3148 | 6000 | 7000 | 10000 | 14000 | 32000 |
Motor | 15 | 18.5 | 22 | 37 | 55 | 110 |
Cpacity (kg/h) | 70 | 100 | 150 | 250 | 400 | 750 |
Screw rotation | Heterodromous external rotation | |||||
