Specifications
304 stainless steel pipe /tube1.Certificate:ISO9001:2008
2.High quality and competitive price
3.Stock information:in stock
304 Stainless Steel Pipe/tube
304 Stainless Steel Pipe/tube
Stainless Steel Tubes & Pipes are divided into square,rectangular and round types with different finishing.
1.Standard and Material
GB standard:GB/T 14976-2002,GB/T 14975-2002,GB/T 13296-91,GB/T 13296-2007
Material:0Cr18Ni9,00Cr19Ni10,1Cr18Ni9Ti,0Cr18Ni10Ti,0Cr17Ni12Mo2,00Cr17Ni14Mo2,0Cr18Ni12Mo2Ti,
0Cr19Ni13Mo3,00Cr19Ni13Mo3,0Cr18Ni11Nb,1Cr19Ni11Nb,0Cr25Ni20,0Cr26Ni5Mo2
ASME : ASTM A312,ASTM A213,ASTM A269,ASTM A789,ASTM A790,ASTM A511
Material:TP304,TP304L,TP304H,TP321,TP321H,TP316,TP316L,TP316H,TP316Ti,TP317,TP317L,TP347,
TP347H,TP310S,N08904,S31803,S32205
EN:EN 10216-5,DIN 17456,DIN 17458,DIN EN ISO 1127
Material:1.4307,1.4306,1.4301,1.4541,1.4550,1.4335,1.4404,1.4401,1.4571,1.4436,1.4435,1.4439,
2.Specifications
Outer Diameter: 6~250mm; Wall Thickness: 0.6~150mm; Maximum Length 2-12m,
3.Surface
2B, 2D, BA,No.1 No.3, No.4, No.8, 8K, HL(Hair Line) ,Polished
4.Shape
Round,rectangular,square
5. Applications
Petroleum, chemical industry, chemical fiber, smelt, medical
machinery, papermaking, heat preservation and refrigeration, mechanical
equipment, food, electricity, water conservancy, architecture, aerospace,
navigation shipbuilding, environmental protection and boiler heat exchanger
American Standard(ANSI)
CHEMICAL COMPOSITION(%)
| Grade | C (Max) | Mn (Max) | P (Max) | S (Max) | Si (Max) | Cr | Ni | Mo | Nitrogen (Max) | Cu/ Others |
| 1.4301 | 0.07 | 2.00 | 0.040 | 0.030 | 1.00 | 17.00~19.50 | 8.00~10.50 | 0.11 | ||
| 1.4307 | 0.030 | 2.00 | 0.040 | 0.030 | 1.00 | 17.50~19.50 | 8.00~10.00 | 0.11 | ||
| 1.4306 | 0.030 | 2.00 | 0.040 | 0.030 | 1.00 | 18.00~20.00 | 10.00~12.00 | 0.11 | ||
| 1.4541 | 0.08 | 2.00 | 0.040 | 0.030 | 1.00 | 17.00~19.00 | 9.00~12.00 | Ti:5C~0.7 | ||
| 1.4550 | 0.08 | 2.00 | 0.040 | 0.030 | 1.00 | 17.00~19.00 | 9.00~12.00 | Nb:10C~1.00 | ||
| 1.4335 | 0.020 | 2.00 | 0.025 | 0.010 | 0.25 | 24.00~26.00 | 20.00~22.00 | 0.20 | 0.11 | |
| 1.4404 | 0.030 | 2.00 | 0.040 | 0.030 | 1.00 | 16.50~18.50 | 10.00~13.00 | 2.00~2.50 | 0.11 | |
| 1.4401 | 0.07 | 2.00 | 0.040 | 0.030 | 1.00 | 16.50~18.50 | 10.00~13.00 | 2.00~2.50 | 0.11 | |
| 1.4571 | 0.08 | 2.00 | 0.040 | 0.030 | 1.00 | 16.50~18.50 | 10.50~13.50 | 2.00~2.50 | Ti:5C~0.7 | |
| 1.4436 | 0.05 | 2.00 | 0.040 | 0.030 | 1.00 | 16.50~18.50 | 10.50~13.00 | 2.50~3.00 | 0.11 | |
| 1.4435 | 0.030 | 2.00 | 0.040 | 0.030 | 1.00 | 17.00~19.00 | 12.50~15.00 | 2.50~3.00 | 0.11 | |
| 1.4439 | 0.030 | 2.00 | 0.040 | 0.030 | 1.00 | 16.50~18.50 | 12.50~14.50 | 4.00~5.00 | 0.12~0.22 |
The above is for reference only
Contact person:Ms Helen 0086-15822006452
