Specifications
100 pair telephone cable1.facttory price
2.Type:HYA outdoor
3.Fast delivery
4.ISO9000 ISO9002 certification
HYA 100 pair telephone cable with conductor BC wire and cable
| Product Description |
1) 0.5 mm pure copper conductor
2) HDPE insulation, The insulated lines are separated by 10 colors according to the standard requirements.
3) Insulated single line: solid polyolefin insulated single line. The insulated lines are separated by 10 colors according to the standard requirements.
4.) Insulated pair lines: wring two single lines together with different pitches according to the chromatogram composition that required.
Features:
1. Reference Standard :YD/T322-1996
2. Use the occasion :Pipeline overhead
3. Rated Temperature :-30 ~ +60 °C
4. Operating temperature :-5°C
5. Rated Voltage :30 V
6. Application :
Mainly used to transmit audio, 150 kHz and below the analog
signal and the 2048 kbit / s and the following digital signal
Electrical properties
| Item | Units | Index | |
| Single-wire DC the resistance of Max.+20°c | Ω⁄km | Conductor Diameter(mm) | |
| 0.32 0.40 0.50 0.60 0.70 0.90 | |||
| 236 148 95 65.8 48 29.5 | |||
wire of DC the resistance unbalance+20°c (the average not larger than the maximum) | ‰ | 2.5 1.5 1.5 1.5 1.5 1.5 | |
| 6 5 5 5 5 4 | |||
Insulation resistance of the minimum+20°c Between each insulated conductor and other grounded and shielded insulated conductors | MΩ.km | Non-filling filling | |
| ≥10000 ≥3000 | |||
Insulation electric strength | Between the wires(3s⁄60s) | kV | 2.0⁄1.0 |
| Between the conductor and the shield(3s⁄60s) | 6.0⁄3.0 | ||
Working capacitance | Below 10 pair of cable:average⁄maximum | nF⁄km | 52.0±2.0⁄57.0 |
| over 10 pairs of cable:average⁄maxium | 52.0±4.0⁄58.0 | ||
capacitive unbalance | Between wire and wire:maxium | pF⁄km | 0.32 0.4 0.5 0.6 0.7 0.9 |
| Between wire and ground :small average | 250 250 250 200 200 200 | ||
| Between wire and ground:maxium | 570 570 570 490 490 490 2630 | ||
Inherent attenuation | Cable more than 10 pairs of non–filling: | db⁄km | 0.32 0.4 0.5 0.6 0.7 0.9 |
| 150kHz Average≤ | 16.8 12.1 9 7.2 6.2 4.8 | ||
| 1024kHz Average≤ | 33.5 27.3 22.5 18.5 15.8 12.6 | ||
| cable more than 10 pairs of filling: | |||
| 150kHz Average≤ | 16 11.7 8.2 6.7 5.7 4.4 | ||
| 1024kHz Average≤ | 31.1 23.6 18.6 15.8 13.5 10.4 | ||
Near-end crosstalk | All the combination between the pairs of wire in 10 pairs and below of cable | db | ≥53 |
| All the combination between the pairs of wire in 20 or 30 pairs and the basic unit | ≥58 | ||
| All the combination between the pairs of wire in adjcent to the basic unit | ≥64 | ||
| Super-unit,two relatively basic units of all combinations | ≥64 | ||
| Different super-flat line for all combinations of the basic unit | ≥79 | ||
FEXT defense degree 150kHz | Any wire pairs of combined | Minimum≥58 | |
| The basic unit or 30 pairs of the cable inside between groups | Power average≥69 | ||
| All the combination between the pairs of wire below in 20 pairs of cable | Power average ≥68 | ||
| Shielding of the continuity of the ribbon | continue | ||
| Cores mixed wire‚wire break | Not mix‚break | ||
| Product Picture |
| Our Factory |
