Sc/apc Electric Simplex Binding Post Fast Connector

Name: Sc/apc Electric Simplex Binding Post Fast Connector
Brand: szrunxiang
SKU: 105881245
Availability: InStock

Shenzhen Runxiang Telecommunication Technology Co., Ltd.

US$ 2.37 - 2.87 MOQ: 3000 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

szrunxiang

Model Number:

sc/apc connector

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name szrunxiang

Model Number sc/apc connector

Specifications

1.sc/apc fiber optical connector
2.factory price
3.the max MOQ is 500000
4. have pass the ISO9001:2000

sc/apc electric simplex binding post fast connector

feature :

1.sc/apc fiber optical connector
2.factory price
3.the max MOQ is 500000
4. have pass the ISO9001:2000

the use way of the sc/apc connector cable

DATA SHEET

ITEM	Technical Parameters
Applicable for	Drop cable.Indoor cable
Optical fiber diameter	125μm ( 657A & 657B )
Tight buffer diameter	250μm
Fiber mode	Single mode
Operation time	About 100s(no fiber cut)
Insert loss	≤ 0.3dB(1310nm & 1550nm)
Return loss	≤ -40dB
Fastening strength of naked fiber	>5 N
Fastening strength of naked fiber holder	>10 N
Tensile strength	>50 N
Using temperature	-40~+75°C
On-line tensile strength (20 N)	ΔIL ≤ 0.5dB ΔRL ≤ 5dB
Mechanical durability (500 times)	Δ IL ≤ 0.5dB Δ RL ≤ 5dB
Drop-off test (drop-off height 4m, once per direction, totally 3 times)	ΔIL ≤ 0.5dB ΔRL ≤ 5dB
