ZX7550 Milling Drilling Machine Benchtop Milling Machine
We Manufacture. Stock. Distribute
1. Main Feature
Gear-Drive Vertical and Horizontal Milling Head
Dovetail Table Guideways Withstand Larger Overturning Moment
Work Table Surface and Guideways Hardened by Supersonic Frequency Quenching (Depth 2-4MM)
Work Table and Guideways Made by HT200-250 High Strength Cast Iron
Rotary Head
Digital Readout (optional)
Oil Receiver (optional)
Actuator (optional)
CE ISO Certificated
18 Months Warranty
Professional Design, Easy Operation
2.Specifications
Specifications |
ZX7550C |
ZX7550 |
Max. Drilling Dia. (mm) |
50(2") |
50(2") |
Max. Horizontal Milling Dia. |
100 |
100 |
Max. Vertical Milling Dia. |
25 |
25 |
Max. Boring Dia. |
120 |
120 |
Max. Tapping Dia. |
M16 |
M16 |
Spindle Taper |
ISO30,R8,MT4 |
ISO30,R8,MT4 |
Spindle Speeds Range (V:Belt/Gear) |
115-1750(8) |
2300-1825(8) |
Spindle Travel |
120 |
120 |
Table Size (mm) |
800*240 |
800*240 |
Table Travel (X.Y.Z) (mm) |
400*230*350 |
400*230*350 |
Main Motor Power (KW) |
0.85/1.5 |
0.85/1.5 |
N.W./G.W.(Kg) |
610/770 |
610/770 |
3. Aceessories
4. Optional Cutters
5.Application Areas
milling machine
pallet or wooden case
