X6332B & X6332C Universal Radial Milling Machine

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Tianjin, China

Brand Name:

L&T Mechanical & Electrical Equipment Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang of Tianjin Port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Tianjin, China

Brand Name LT

Model Number X6332B

Type Universal

CNC or Not Normal

Voltage 220V/240V/360V; 50/60Hz

Power(W) 3.7KW;2.2KW

Dimension(L*W*H) 1700*1520*2260mm

Weight N.W./G.W.: 1550KG/1650KG

Certification CE ISO9001:2008

Warranty 18 Months

After-sales Service Provided Engineers available to service machinery overseas

X6332B & X6332C Universal Radial Milling Machine

Product Description

We Manufacture. Stock. Distribute

·Rectangular Table Guideways With High Stability

·Hardened And Ground Table Surface

·Automatic Feeds on X,Y Axis, Motorized Lifting and Falling of Table on Z Axis

·Headstock Swivels ±45°, Vertical Milling Spindle Auto-feeding

Easy Operation

Specifications	X6332B Universal Radial Milling Machine	X6332C Universal Radial Milling Machine
Spindle Taper (mm)	7:24 ISO40	7:24 ISO40
Distance from Spindle to Table (mm)	150-490	150-490
Distance from Spindle to Column (mm)	200-550	200-550
Spindle Speeds (R.P.M)	(20step)78-6980(V), 400-1300(H)	(20step)78-6980(V) ,400-1300(H)
Table Size (mm)	1250*320	1250*320
Table Travel (X.Y.Z) (mm)	800/300/350	800/300/350
Feeding Range of Longitudinal, Cross Travel	(8 step)30-740(Rapid feed 1080)	(8 step)30-740(Rapid feed 1080)
Auto-feeding of Z-axis	560	560
T-slot (Number-width-distance)	3/14/70	3/14/70
Main Motor Power (KW)	3.7;2.2	3.7;2.2
Overall Dimension (mm)	170015202260	170015202260
N.W./G.W.(Kg)	1550/1750	1650/1850
