Home > Products > Machine Tools > VMC1060 Factory Price Box way Vertical Machine Center
VMC1060 Factory Price Box way Vertical Machine Center
- 20 Set / Sets per Month
- Tianjin/Qingdao China
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Tianjin, China | Brand Name: | ME |
Model Number: | VMC1060 | Type: | Vertical | CNC or Not: | CNC |
Voltage: | CUSTOMIZED | Power(W): | 11/15 | Dimension(L*W*H): | 3400x2750x2800mm |
Weight: | 7500 kg | Certification: | CE, ISO | Warranty: | 18 MONTHS |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
WOODEN CASES
Product Description
VMC1060 Factory Price Box way Vertical Machine Center
Features
Use strong rigid casting steel X/Y/Z axes are supplied with rectangular guide ways, medium frequency quenching and precisely grinding.
Guide-ways are with plastic sticker, and be precisely scrapped.
Original high speed and high precision TAIWAN spindle.
Whole machine be equipped with pump of large flow and high lift pump to insure cooling under high-speed cutting.
Specification | |||
Model | VMC1060 | ||
TRAVEL | X/Y/Z Axis travel(mm) | 1000/600/600 | |
Distance from spindle nose to worktable(mm) | 180-780 | ||
Distance from spindle center to column(mm) | 600 | ||
WORKTABLE | T slot(width x No. x space)(mm) | 18x5x120 | |
Worktable size(L.mm x W.mm) | 600x1300 | ||
Max. loading on worktable(kg) | 800 | ||
SPINDLE | Motor power(kw) | 11/15 | |
Spindle speed(r.p.m.) | 60-8000 | ||
Spindle taper | BT50 | ||
Spindle bearing | P4 | ||
FEEDING | 3 axes fast moving speed | m/min)(X&Y) | 18 |
(M.min)(Z) | 15 | ||
Cutting feeding rate(mm) | 1-5000 | ||
X/Y axis ball screw(diameter x space)(mm) | 40x10 | ||
Z axis ball screw(diameter x space)(mm) | 40x10 | ||
Min.set and moving unit(mm) | 0.001 | ||
ATC | ATC type | Manipulator | |
Time of tools automatic changing(near)(s) | 3 | ||
ATC capacity | 24 | ||
Max.diameter of tool(near)(mm) x Weight(kg) x length(mm) | 80x7x300 | ||
3-AXIS ACCURACY | Position accuracy(300mm) | ±0.005 | |
Repeated postion accuracy(300mm) | ±0.003 | ||
OTHER | Machine weight(kg) | 7500 | |
Air pressure(kg/cm2) | 6 | ||
Porwer of cutting coolant pump(W) | 370 | ||
Porwer capacity(KVA) | 20 | ||
Overall size(L x W x H)(mm) | 3400x2750x2800 | ||
CNC controller system | FANUC, Mitsubishi, Siemens828D, GSK218M |
Other hot sale models
Click Here Click Here Click Here
Click Here Click Here Click Here
Click Here Click Here Click Here Click Here
Our factory specialize in machinery for more than 20 years, we also supply all kinds of accessories of milling/drilling machines and cnc milling machines. Please contact our sales for more details.
Thank you!
VMC1060 Factory Price Box way Vertical Machine Center
L&T EQUIPMENT
Company Profile
Our company is a major import and export enterprise located in the port city Tianjin, China. Awarded multiple contracts by the World Bank and the Asian Development Bank, we have provided products worthy of billions of dollars to domestic and overseas partners on an annual basis since 1994. Our corporate mission is to promote our business by continually exceeding our customers' expectations for service and reliability.
Our company currently exports more than 400 categories of products to more than 100 countries worldwide. Our main export products are machine tools and accessories, valves, engineering machinery, universal machinery, agricultural machinery, electric motors, water-submersible pumps, diesel generating sets, conveyor pulleys, hydraulic cylinders, survey equipment, and so on.
With the rapid development of the Chinese market in recent years, internal demand for foreign products has expanded exponentially. To serve this demand, our company now imports an extensive range of products, including heavy forging equipment, paint sprayers, industrial lubricants, industrial liquid soap, laboratory apparatuses, flexible bus bars, fire extinguishing facilities, and power generator sets.
We are continually looking for reseller partners to distribute our products and supplier partners to expand our product base. Please contact us if you have a need. We look forward to serving you.
ISO9001:2008 certified.
