XK7132 Vertical Milling Machine

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Tianjin, China

Brand Name:

L&T Mechanical & Electrical Equipment Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Tianjin, China

Brand Name ME

Model Number XK7132

Type Vertical

CNC or Not Normal

Voltage 220V/240V/380V; 50-60Hz

Power(W) 5HP

Dimension(L*W*H) 2100X1900X2340mm

Weight N.W.:2300kg

Certification CE, ISO9001:2008

Warranty 12 Months

After-sales Service Provided Engineers available to service machinery overseas

XK7132 Drilling Milling Machine

Product Description

Main Feature

CE Standard Electrilc Device; ISO9001: 2008 Quality Certificate.

Easy operation,China factory

Good helper for your machining and maintanance work in your workshops.

Specification

Specification	Unit	XK7132	XK7132A
Table size	mm	1370X300	1370X300
T-slots (No./width/pitch)	mm	3X18X80	3X18X80
Longitudinal travel	mm	770	770
Cross travel	mm	450	450
Vertical travel	mm	440	440
Distance between spindle and table surface	mm	130-570	80-520
Table rapid feed speed(X)	mm/min	4000	4000
Table rapid feed speed(Y)	mm/min	4000	4000
Rapid feed speed(Z)	mm/min	3000	3000
Spindle hole taper	---	BT40	BT40
Stroke of spindle quill	mm	127	-
Automatic spindle feed	mm/rev	0.04/0.08/0.15	-
Spindle speed range	r/min	43-3225(variable)	5000
Spindle speed range	r/min	65-4660 (16steps)	5000
Main motor power	HP	5	3.7
Torque of X/Y/Z axis AC servo motor	N.m	10/10/10	10/10/10
Overall size	mm	2100X1900X2340	2100X1900X2340
Net weight	kg	2300	2300
