Best sales!Fiber laser marking machine for jewely marking laser pretzel machine cnc laser soldering machine
Superwave Laser Technology Co.,Ltd is a professional China fiber laser marking and engraving machine manufacturer, with professional factory we are always able to offer you discount fiber laser marking and engraving machine, all-in-one marking and engraving laser system with reliable quality.
Product Introduction
The fiber laser marker has a homogeneous structure, any optical soiling, any power coupling losses and it has an air cooling system. In contrast to other laser machines, this laser machine has a high efficiency and reliability. Efficiency and a long duration of usage are the main arguments for customer's choice and usage of this optical fiber laser marking machine.
Essential features
The laser beam has an excellent quality: In comparison with traditional laser marking machines, the laser marking machines of series SW-FLM have the absolute superiority. The output for the base mould is focused with a facular diameter less than 20nm. The divergence angle is ¼ of the semiconductor pump laser. Especially suitable for precise and extremely precise laser marking:
Low running costs:
The electrical light transfer efficiency achieves 30% most greatly; the energy consumption is less than 800W, which is 1/10 by the lamp during laser marking pumped solids. The long-term use may save a lot of disbursement of the users.
This laser machine has a long duration of life:
The fiber laser marking machines uses two levels of tube achievement for pump source. This machine uses a unique pump coupling technology and its averaged working time amount to 100,000 hours. This laser machine has an exquisite volume and it is suitable for adverse circumstances: The optical fiber laser machine has an extremely flexibility, designs extremely nimble and has a compact design. The glass fiber surface area / volume ratio is high and has a good effect of radiation. It is not necessary to use an enormous water cooling system - an air cooling system is sufficient. Even if attacking high, high vibration, high temperature, dust and other adverse circumstances, this laser machine continue normal work. Exempts the maintenance operation.
Data Sheet:
| Model | SW-FLM Fiber laser marker series |
| Mean laser power | 10W;20W;30W;50W |
| Laser wavelength | 1064nm |
| Laser Repetition frequency | 20-100KHz |
| Marking area | 110×110mm |
| Marking size optional | 50x50mm,70x70mm,150x150mm,175x175mm,200x200mm |
| Marking depth | ≤0.8mm |
| Linear speed | ≤10000mm/s |
| Min. line width | 0.01mm |
| Min. letter | 0.2mm |
| Repeatability | ±0.002mm |
| Supported format | Support AI,PLT, DXF, BMP,JPG file, etc. |
| Power supply | AC220V±10%/50Hz-60Hz, AC110V optional. |
| Power consumption | 0.8KW |
| Laser cooling | Air cooling |
| Host dimension(L*W*H) | 1200x630x1400mm |
Sample Pictures
