Portable Micro Watch and Jewelry Manual Laser Spot Welding Machine
- Applications
Jewellery/Jewelry laser spot welder is mainly use in jewelry, eyeglasses frame, dental, watches and golf club industry. It can process all metals used for making jewelries such as gold, silver, platinum, titanium, steel, palladium and their alloys. It is mainly used for manufacturing and repairing jewelry, glasses, dental, watches and golf stick, as well as precisely welding a variety of micro and heat-sensitive parts, just like nickel straps of batteries, hairsprings, down-leads of IC.
- Advantages
1. High single-pulse energy with long lifetime U.K. laser cavity.
2. High effieciency YAG crystal to ensure the best beam quality and energy.
3. Design for Feeling and safety operation.
4. Stable laser power supply to ensure continuous 24hours.
5. A variety of configuration options according to your needs.
- Specifications
| Model | SW-SW100 | SW-SW150 | SW-SW200 |
| Laser type | YAG lamp pump pulsed | YAG lamp pump pulsed | YAG lamp pump pulsed |
| Max.output power | 100W | 150W | 200W |
| Max.pulse energy | 80J | 100J | 120J |
| Peak power | 5KW | 6KW | 7KW |
| Pulse duration | 0.1-20ms | 0.1-20ms | 0.1-20ms |
| Pulse frequency | 1-50Hz | 1-50Hz | 1-50Hz |
| Focal diameter | 0.1-2.0mm | 0.1-2.0mm | 0.1-2.0mm |
| Cooling system | External water cooling Internal cooling system optional | External water cooling Internal cooling system optional | External water cooling Internal cooling system optional |
| Vision system (Standard) | Stereo microscope 10X (more optional) | Stereo microscope 10X (more optional) |
Stereo microscope 10X
(more optional)
|
| Control System | Microchip CPU | Microchip CPU | Microchip CPU |
| Power supply | AC220V/1Ph/50Hz | AC220V/1Ph/50Hz | AC220V/1Ph/50Hz |
| Net weight | 120kg | 140kg | 140kg |
I. Jewellery/Jewelry Repair
II. Glasses Repair
III. Dental Welding
IV. Golf Stick Laser Welding
