Aluminium Welding Robotic Laser Welding Machine Price List
Principle
- Laser passes through aligning lens and then focuses on workpiece after it is transmitted by optical fiber.
- SW-FLW50/80/150/300/600 Fiber Laser Welding Machine adopts Germany's advanced technical to weld the mould and mechanical parts in all sizes ( large, middle and small ).
- Our Fiber Laser Welding Machine uses closed-loop energy feedback system. The CPU board can Real-time dynamic adjustment of the laser energy, and can keep the all shot with the same energy and laser power, which makes the weld line even and reliable with low stress and non-crackle effect.
Features of Fiber Laser Welding
- Closed-loop energy feedback system.
- Fiber laser transition, excellent laser beam, slim laser spot, flexible installation.
- Customized with automatic work fixture to realize mass production.
- Set the shape of laser wave randomly and 99 sets data can be stored. Closed-circuit control.
- Installed with LCD and CCD monitor.
- Be able to work in hard working environment, such as lashing, shaking, high temperature and dusty.
- Pocket laser head can move in the direction of X, Y and Z and rotate in different angle and direction to locate on work pieces.
- Suitable for large, middle and compact mould amendment.
Specifications
Fiber Laser Welding Machine for Mold Repair | |||||
Technical parameters |
SW-FLW50 | SW-FLW80 |
SW-FLW150 |
SW-FLW300 | SW-FLW600 |
Max laser power |
50W |
80W |
150W |
300W |
600W |
Max. laser pulse energy |
50J |
50J |
80J |
100J |
100J |
Laser wavelength |
1064nm |
||||
Min. diameter of focus point |
0.2mm |
||||
Min. welding spot size |
0.1mm |
||||
Welding depth |
Max.2mm/SS |
Max.3mm/SS | |||
Pulse width |
0.1ms-20ms |
||||
Pulse frequency |
1-100Hz |
||||
Controlling system |
SCM |
||||
Observing system |
microscope |
||||
Locating system |
CCD and monitor |
||||
Laser host dimension(mm) |
630W*1020D*900H |
630W*1020D*900H |
|||
Cooling system |
air cooling/water cooling system |
water cooling system | |||
Fiber model |
SI/GI0.2~0.6mm |
||||
Quality Guarantee & After-Sales Services
Whole Production Line
l Free Training by VCD: We will supply the machine with <Training VCD> , <User's Manual> and <Instruction Book> in English for installing, operation, maintenance and trouble-shooting, and shall give technical guide by E-mail, fax, telephone, MSN, ICQ and so on, when you meet some problems of installation, using or adjusting. (Recommend)
l Free Training in Superwave Laser's Factory: You can sent operator to Superwave Laser factory for free training. Superwave Laser will offer professional guide for free. It is direct and effective face-to-face training. Here we have well-assembled equipments, all sorts of tools and testing facility.
l Our engineer can do a door-to-door instruction training service at your local site. We need your help to deal with the visa formality, prepaid traveling expenses and accommodation to us during the business trip and service period before their dispatch. It's better to arrange a translator for both of our engineers during the training period.
Air Ticket + Local accommodation bears by buyer
Free samples services, please contact me (+86 133 1628 9835/Skype: superwavelaser5) !
