Round And Counter Cooling Tower
1.Tower body: made of FRP composite material, imported surface gel coat materials containing anti-ultraviolet stabilizer in color, with the merits of smooth surface , anti-aging, difficult to fade.
2.Motor: famous brand motor with hermetic waterproof, protection grade IP55, insulation F grade
Heat elimination film using Taiwan PVC and imported milk white PP, the maximum temperature resistance of PVC and PP 120degreel
3.Water Distribution system: with the rotating tube type water distribution , water distribution device is made of ABS or copper alloy, with long-standing service and uniform water distribution
4.Transmission: all rotating components adopt imported bearing with high precision and low repair rate, selects imported strong “V” shape belt with high strength , wear resistance and long service life.
5.Use metal parts for the outer pipes hitch of cooling tower and flange, adopt copper alloy swivel, which has reduce broken of tube connection hitch, flange and abraded of swivel in the largest degree.
6.Good material and reasonable design of the tower body ensure the long service life and cooling effect.
7.Picture of the product
Water inlet temperature:37°C
Water outlet temperature:32°C
Wet bulb temperature:28°C
Dry bulb tem peranure:31.8°C
Atmospheric pressure:9.94×10000Pa
Material: glass fiber reinforced plastic (GFRP)
1.Should avoid installed in waterproof channel, easy to reflect the walls of volume, must be packed in roof or air circulation place.
2.WIth two or more cooling tower and, attention shall be paid to minus its spacing.
3.Should not be installed in all outer wall or tight place, and should pay attention to minus its exterior wall spacing.
4.Should avoid to install a soot and dust more places, the top jams film.
5.Should be far away from the kitchen and boiler room wait until a hot place.
1.Provide install video if necessary.
2.Quality guarantee is 12 months.
3.If it was proved due to the quality problem,we will bear all cost for replace during quality guarantee time.
4.Oversea technical guidance.
5.Provide foundation drawing.
WHENZHOU SANHE REFRIGERATIONE EQUIPMENT CO.,LTD
1.Established:2005
2.Employees: 11 - 50 People
3.No. of R&D Staff : 11 - 20 People
4.No. of QC Staff: 5 - 10 People
5.Management Certification: ISO 9001:2000
6.Main Markets: North America South America Eastern Asia Western Europe
1.Q:Are you a factory or a trading company?
A:Cooling tower manufacturer with 50 works.
2.Q:What's your MOQ of this term?
A:1 SET.
3.Q:Where is your Loading port?
A:Ningbo port,China
4.Q:What's your company's available production capacity?
A:200 SETS per month.
5.Q:How about the packing of this model?
A: Spare parts packing with wooden case, 20 feet container, 40 feet container
6.Q: How about the payment?
A:The 50%TT deposit in advance,50%TT balance before shipment.
