Home > Products > Big Bottle Production Line > Automatic 3-10L Bottle Filling Machine
Automatic 3-10L Bottle Filling Machine
- SHANGHAI PORT
- T/T Money Gram Credit Card
You May Like
-
Automatic Barrel Filling Machine
-
Automatic 5 Gallon Water Filling Machine
-
Automatic Bottle Blow Molding Machine /Blowing Machine
-
Semi-automatic Bottle Blow Molding Machine /Blowing Machine
-
Water Bottle Blow Molding Machine /Blowing Machine
-
Semi Automatic Carbonated Bottle Blow Molding Machine /Blowing Machine
Product Details
| Condition | New | Application | Beverage, Chemical, Medical | |
| Packaging Type | Bottles | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 380V/220V | Power | 3.2KW | |
| Place of Origin | Jiangsu, China | Brand Name | LINKS | |
| Model Number | LXGF4-4-1 | Dimension(L*W*H) | 2780*1965*2100mm | |
| Weight | 3200KGS | Certification | CE, ISO, SGS | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Automatic 500BPH Pure Water Bottling Machine/Plant
BXGF4-4-1 three-in-one linear machine for PET Big bottle integrates the function of rinsing, filling and capping together. Based on advanced technology overseas, and designed according to water filling processing demands
Model | BXGF4-4-1 |
Amount of working position | Rinsing 4, filling 4, capping 1 |
Production capacity | 500BPH(5000ml) |
Pressure of air source | 0.4Mpa |
Air consumption | 0.8m3/min |
Rinsing water pressure | 0.2-0.25Mpa |
Rinsing water capacity | 0.3T/H |
Main motor power | 1.8kW |
Total power | 2.5kw |
Dimension | 4200X1400X2100mm (L×W×H) |
weight | 2500kg |
We also provide the Complete Automatic Pure Water Bottling Plant
It Includes 4 main parts:
1/ Plastic bottle blow molding machine
2/ Water cleaning system
3/ Water washing, filling, capping machine.
4/ Conveyor system, labeling machine, dating machine, film wrapping machine
The complete line main description:
1/ The plant can produce different volume bottles, from 3000ml to 10000ml bottles, round and square bottles, plastic and glass bottles. It is very easy to change the different bottle molds.
2/ The plant is highly automatic, you can operate on the touch screen to adjust the machine speed and working.
3/ We have different speed plants, commonly,500BPH, 800BPH, 2000BPH...
4/ The material is stainless steel 304, food grade much clean and safe.
5/ We provide the engineers for customer installation, training in customer's factory.
Electric Components Brands Supplier
Main composition | Description Supplier |
PLC | Mitsubishi (Japan) , Siemens (Germany) |
Touch screen | Weinview(Taiwan) |
Frequency converter | Mitsubishi (Japan) , Siemens (Germany) |
Air switch | Schneider (France) |
Breaker | Siemens (Germany) |
Contactor | Siemens (Germany) |
Photoelectric switch | Omron (Japan) |
Water Treatment System
Water 3 in 1 Rinsing, Filling, Capping Linear Monoblock Machine
Labeling Machine&Packing Machine
Spare Parts On Machines
1. We provide the complete machines' layout, design according to customer's factory.
2. We provide the complete English manual book for customer, all the machines' touch screen operation is English words, we have Russia, Spanish, Portuguese, French..ect to choose.
3. After delivery, we will send our engineer to customers' factory to install the machines and also train workers how to operate and maintenance. Engineer's salary: 80USD/Per day.
4. Our warranty time is 18 months after the machines installation.
5. We provide the 12 months easy broken spare parts as free, and also provide the spare parts book to customer.
6. Payment method: 30% T/T as deposit after signature the contract, 70% T/T or L/C after inspection before delivery.
7 Common delivery time: 45-70days after confirm the bottle and cap design.
