High Speed Can Depalletizer Machine

Model

XD-600

XD-600A

XD-600B

Production capacity

0-250cans/min

0-400cans/min

0-600cans/min

power

2.5kw

2.5kw

2.5kw

weight

2500kg

2800kg

2900kg

height

2660mm

2660mm

2660mm

Applicable pallet

1100×1400mm

1100×1400mm

1100×1400mm

dimension

7500×2100×3150mm

8500×2600×3150mm

9500×3500×3150mm

Packaging Details:

PLT/SIMPLE PACKAGE

Delivery Detail:

45 days after down payment

       Summary:

1.It is applicable to automatically unload empty cans.

 2.It lifts the empty cans that are piled on the plank one floor by one floor and pushes to the net conveyer.

3.It can match different kinds of washer.

4.It is the perfect machine for large and medium canning plant. It can save much manpower and increase production capacity.

        Principle:

     1. Over by the forklift to stack pallets of empty cans,pallets placed on the conveyor, and then the conveyor and transported to the host platform pallet movements.

    2.  Pallet positioning platform is empty after unloading pallets up to the tank height, when unload the empty cans, the empty pallets put down on the conveyor.

    3.   All action of the rise and the decline are controlled by stem of self-locking device, and separately adjust the speed of rise and the decline to meet the operational needs.

    4.  Unloading device is the use of empty air cylinder and hydraulic motor driven devices to push the whole empty cans on the net conveyor, and then return to ready position and continue to be launched next level.

   5.  All actions by the photoelectric switch control positioning and movement to choose a row or a single tank unloading a revolving basis.

   6.Empty space after unloading let conveyor by empty space pallet transferred to Taiwan vertebral plot, and then followed to a certain height of the stack, and then the pallets out of forklift. It into pile direction, the direction of the tank, console users location can be flexible according to changes, but the user plane location map should be provided.

Specifications:

Production capacity

0-250cans/min

Power

2.6kw

Weight

2500kgs

Dimension

7500×4500×3500mm
