Auto Ironing and Sealing Metal Zipper Machine
Technicial specifications:
Model |
QLQ-IWM |
Machine name |
Metal Zipper Ironing and Sealing Machines(Lacquer M/C) |
Average output |
1000-2500 |
Power |
15KW |
Voltage |
380V |
Dimension (CM) |
320×65×200 |
Specification |
No.3-No.10 |
Working Air pressure |
4KG/CM2 |
Producing cost |
0.02 Yuan (RMB)/ strip |
Heating up time |
15 Min to reach preheated temperature |
Surface hardness of lacquer |
>4H |
1. This machine is to iron, finalize the design, seal the plated- gold or silver metal zipper. Then, the zipper will be shiner, harder and have there dimensions.
2. With speed-adjustment and special frequency conversion, environment air drafting system of radian ironing wheel, cold air system and advanced technology of auto waxing, the machine enjoy good energy efficient system.
3. Its main components consist of international-level products with machine case made of heat protection material. Therefore, the technical index of this machine can reach a high level in the same sectors.
4. The period of ironing is long enough to guarantee the smoothness, inner radian, shrinkage rate and waterproof intensity.
5, Based on the TF109B-13, it is developed to be more suitable for long zipper.
Advantages:
|
TF109B-17 Metal Zipper Ironing and Sealing Machine(Lacquer M/C) |
Normal Ironing and Sealing Machine |
Length and feature of leading tape |
About 300 meters Can be ironed at a low temperature |
About 80meters Must be ironed at a high temperature |
Time and feature of lacquering or ironing |
>10Min Good waterproof nature |
4Min Bad waterproof nature |
Shrinkage rate |
60cm shrinkage<0.5cm |
60cm shrinkage>0.5cm |
Producing Cost |
0.02 Yuan (RMB)/ strip |
Above 0.03 Yuan (RMB)/ strip |
Speed |
1200strip/H |
600strip/H |
|
Effectiveness |
Straightness teeth, Water ripple kept at the tape edge , Same length kept as the zipper itself |
Easy deformation |
