Help CenterHot Sale CE Multifunction Upgrade 10 in 1 Album Photobook Making Machine (S-A10)
Related Products
-
Silicone/Plastic DIY 3D Sublimation Phone Cover Single Protective for IPhone 5US$ 0.6 - 2.99MOQ: 500 Units -
DIY 3D Luminous Blank Sublimation Phone Cover for Ip4US$ 0.6 - 2.99MOQ: 500 Units
-
DIY 3D Sublimation Phone Case for IPAD MINIUS$ 0.6 - 2.99MOQ: 500 Units
-
Phone Cases for Ipad Covers Printing Machine&high Resolution&high QualityUS$ 0.6 - 2.99MOQ: 500 Units
-
China Supplier DIY 3D Sublimation Polymer Phone Case for IPhone 6US$ 0.6 - 2.99MOQ: 500 Units
Glue Binding Machine:
specification:
machine has eleven functions : Creasing ,binding ,heat&cold pressing ,CNC cutting ,corner cutter ,cover making ,
edge holding ,cover corner cutting ,grooving and heat trimming .
1.Delicate design for exporting .Multi-dimensional platform can be worked at the same time with high efficiency .
Combine electric with pneumatic ,easy operation and make sure the albums without deformation ,tackless and
crack
2.Cover making with Trilateral ruler measurement and accurate position
3.The creation of the cover cutter,can help the customers to cut the angle accurately
4.One machine combine making inner sheets with cover of the albums.The CNC cutter with infrared ray to collate
and exquitsite function
5.The creasing knife is aluminium alloy , can be creased with delicate marks and not easy to be broke
6.With cold and heat pressing just up to the customers' demand
7.Grooving ,about temperature ,pressure ,grooving plocation can be adjusted according to the customers
8.Digital temperature control instrument , simple operation and constand temperature automatically ,low cost and
maintainance is accepted
9.Binding with double-side aluminium keep heating and albums are not be transformative
*Creasing width :530mm
*Creasing paper :400-500g
*Trimming thickness:5cm
*Trimming width :510mm
*Trimming size:550*400mm
*Pressing heigth :20cm
*Temperature range :0-100
*Cutting width :460mm
*Cutting accuracy:less than 0.1mm(infrared collation)
*Power supply :AC220V/50HZ
*Power:3KW
*Corner cutter :R3-R10
*Album cover size:18inches-24 inches
*Edge holding width :670mm
*Cover corner cutting size :23mm*5mm
*Grooving width: 520mm
*Net weigth :405kg
*Gross weigth:460kg
*Machine size: 1470*1080*1250
*Packing size:1560*1210*1430=2.7
*Package :Plywood case
Technical parameters
Model |
S-A10 |
Corner cutter |
R3-R10 |
Album cover size |
18inches-24 inches |
Inclined cutting technology |
670mm |
Cover corner cutting size |
23mm*5mm |
Grooving width |
520MM |
Creasing width |
530mm |
Creasing paper |
400-500g |
Trimming thickness |
5cm |
Trimming width |
510mm |
Pressing heigth |
20cm |
