Help CenterTwo-directional Plastic Geogrid Used in Road
Related Products
-
Two-directional Draw and Extend Plastic GeogridNegotiableMOQ: 5000 Square Meters -
Two-directional Fiberglass Geogrid for ConstructionNegotiableMOQ: 5000 Square Meters
-
Biaxial Fiberglass Geogrid for ConstructionNegotiableMOQ: 5000 Square Meters
-
Fiberglass GeogridNegotiableMOQ: 5000 Square Meters
-
Fiberglass Woven Geogrid for BuildingNegotiableMOQ: 5000 Square Meters
Specifications
material: polyestermesh size /mm: 12.5x12.5~25.4x25.4
width:1m-6m
length: 50m~100m
we can made these as customers' demand
USAGE:
It can be widely used in basic engineering, road construction, mine protection, reinforcement groundsill of rives, bank, coast defence projects. Used for supporting and protecting purpose in roadway coal mine.
1. reinforce the carry capacity and prolong the using time of the base;
2. avoid the road subside and crack and keep the road orderliness;
3. be easy to construction, save time and strength, short the time for the project, and save the
servicing;
4. avoid the culvert becoming crack;
5. provide stability for slopes and avoid the losing of the water and soil;
6. reduce the thickness of the underlay and saving the cost;
7. Can replace the wire netting.
technical specification:
Item |
TGSG15-15 |
TGSG20-20 |
TGSG30-30 |
TGSG40-40 |
Quality per meter square g/m2 |
300±30 |
300±30 |
400±40 |
500±50 |
Width m |
4.0 6.0 |
|||
Warp Tensile Strength per meter KN/m |
15 |
20 |
30 |
40 |
Weft Tensile Strength per meter KN/m |
15 |
20 |
30 |
40 |
Warp elongation ≤% |
16 |
|||
Weft elongation ≤% |
13 |
|||
Warp Tensile Strength at 2% elongation KN/m |
5 |
8 |
11 |
13 |
Weft Tensile Strength at 2% elongation KN/m |
7 |
10 |
13 |
15 |
Warp Tensile Strength at 5% elongation KN/m |
8 |
10 |
15 |
16 |
Weft Tensile Strength at 5% elongation KN/m |
10 |
13 |
15 |
20 |
