Specifications
material: fiberglassmesh size /mm:12.5x12.5~25.4x25.4
width: 1-6m
length: 50m~100m
we can made these as customers' demand
The product adopt continuous coating fiberglass and as a new ideal highway pavement reinforcement base material ,it is characterized by high tensile strength in both axial and lateral direction, low stretch rate ,high temperature-resistance, alkali-resistance as well as pavement, cement pavement to prevent cracks arise ad prolong pavement service life. It also can be used as basal reinforcement material of hillside, reservoir, harbor, port, water cannel, breast wall, etc
We can produce as the customer’ inquiry.
[APPLICATION]
(1)Road surface reinforcement of road, railway and airport road;
(2) Maintenance, reconstruction and widening of old road surface( asphaltum road or cement concrete road).
(3)Reinforcement of soft soil roadbed, irrigation channels and water dams.
[PROPERTIES]
(1)High tensile strength in both the warp and weft directions;
(2) Low elongation;
(3) Excellent temperature range;
(4) Good anti-age and alkali-resistance;
(5) Reduce construction cost, extend service life of road and prevent deflection cracks.
Product specification and performance parameter
Performancespecification |
TGS-B-25-25 |
TGS-B-30-30 |
TGS-B-40-40 |
TGS-B-50-50 |
TGS-B-80-80 |
TGS-B-50-50-Z Autohesion type |
|
Intensity(KN/m) |
Longitudinal |
25 |
30 |
40 |
50 |
80 |
50 |
Lateral |
25 |
30 |
40 |
50 |
80 |
50 |
|
Breaking elongation % |
≤3 |
≤3 |
≤3 |
≤3 |
≤3 |
≤3 |
|
Grid (mm) |
25.4×25.4 |
25.4×25.4 |
25.4×25.4 |
25.4×25.4 |
25.4×25.4 |
25.4×25.4 |
|
Width (m) |
1-6 |
1-6 |
1-6 |
1-6 |
1-6 |
1-6 |
|
