Specifications
|
Item No. |
Ozone Output (g/h) |
Concentration (ppm) |
Rated power (kw) |
Air dew point |
Cooling method |
Power supply (V/Hz) |
Weight (Kg) |
HW-OW-20 |
20 |
1-10 |
0.9 |
-45 |
cooling water |
350/50 |
130 |
Technical details
|
• High frequency invert power supply system with own international patents. • Micro-gap corona discharge technology, quartz glass tubes honeycomb discharge. • Water cooling system. • Pure oxygen or air as gas feed. • Stainless steel ozone reaction cavity and discharging tubes. • Wecon PLC micro computer control, touch screen human-machine display. • Multiple proteftion designs in case of over current,overvoltage, overheeated, high and low air pressure. |
Why US?
Efficiency& reliable
•Power factor>0.95.
• PFC≥0.95
•The adverage power consumption of per kilogramozone output is about 7 degree.
•Ozone concentration could reach 230mg/l with pure oxygen asgas feed.
•Multiple abnormality protection. Light alarm system.
Easy operatiion
•Ozone concentration adjustable.
•Ozone production adjustable.
•Time switch machine Settings, realize unattended.
•Transport gas without any external equipments during certain scope.
•Group control function, digital remote monitoring
•Real-time analysis and system failure diagnosis.
Application | |||||||||||||
1. Factories and enterprises sterilization and disinfection. | |||||||||||||
2. Public places disinfection, sterilization, removing odor. | |||||||||||||
3. Warehouse and agricultural products keep fresh and anti-corrosion. | |||||||||||||
4. Breeding industry sterilization, disinfection and deodoran. | |||||||||||||
5. Archives and libraries: archives sterilization, mould proof, insect repellent, moth-proofing, etc. | |||||||||||||
6. Water treatment: tap water treatment, waste water treatment, waste water bleaching, color decoloration, reduce BOD and COD. | |||||||||||||
7. Waste air treatment: Odor removal, treatment aromatic hydrocarbon, Benzodiazepines etc. |
