Description
copper tube straighener and cutting machine miany for aluminum tube decoiling, straightening and
cutting.it can be design as single coil tube processing, 2 line, 4 line, 6 lines series. The speed will be little difference against the diameter and material hardness.More requiremenet, pls contact us free.
main parameter
No | Item | Detail | Memo |
1 | tube diameter range | OD 4.0—8.0mm | bigger size for 8-18mm |
2 | tube thickness range | 0.50-1.0mm | / |
2 | tube straightening length range | 100-50000mm | / |
3 | straightening working speed | >=45meter/minute | different as tube size |
4 | Material collection shelf | prepared by the user | / |
5 | length cutting tolerance | +/-1mm | / |
6 | power supply | 380V/50Hz | 3 phases 4 wires type |
7 | motor power | 5.5KW, rev1440/rpm | Material feeding motor |
2.2KW, rev1440/rpm | cutting motor | ||
8 | the pressure the air compressor | 3MPa | Just need 0.6-0.8MPa in working |
9 | dimension | 4000X1000X1350mm | Not included the material collection shelf |
10 | weight | 2000KG | / |
Drawing
