Single Thick Wall Bundy Pipe
- Shanghai port China
- T/T
You May Like
Product Details
| Thickness | 0.50, 1.20 | Section Shape | Round | |
| Outer Diameter | 3.18 - 12.70 mm | Place of Origin | Jiangsu, China | |
| Secondary Or Not | Non-secondary | Application | Other, refrigeration and automobile industry, refrigeration, automobile | |
| Technique | ERW | Certification | Other, SGS | |
| Surface Treatment | Galvanized | Special Pipe | Thick Wall Pipe | |
| Alloy Or Not | Non-alloy |
Product Description
single wall wedled steel tube
THE TYPE OF SURFACE COATING, CONDITION AND CODE STEEL TUBE
type | Coating condition | code |
Without coated | Inner and outer side without coating | SWP |
CU coated | Cu coated on outer side only | SWCu |
ZN Coated a | Outer with white /colour/olive ZN coated | SWZn |
CU coated both sides b | Cu coated on outer and inner side both | SWCuCu |
ZN coated outer CU, coated inner c | Outer Zn coated, inner CU coated | SWZnCu |
a. electric or hot dip galvanized b. made by both sides CU coated steel coil. On the welding line ,to be negotiated c. made by both sides CU coated steel coil | ||
main size OD and thickness
OD /mm | Thickness/mm | |||||||
0.50 | 0.60 | 0.65 | 0.70 | 0.80 | 0.90 | 1.00 | 1.20 | |
3.18 | √ | — | — | — | — | — | — | — |
4.00 | √ | √ | √ | √ | — | — | — | — |
4.76 | √ | √ | √ | √ | √ | — | — | — |
5.00 | √ | √ | √ | √ | √ | — | — | — |
6.00 | √ | √ | √ | √ | √ | √ | √ | √ |
6.35 | √ | √ | √ | √ | √ | √ | √ | √ |
7.94 | — | √ | √ | √ | √ | √ | √ | √ |
8.00 | — | √ | √ | √ | √ | √ | √ | √ |
9.53 | — | √ | √ | √ | √ | √ | √ | √ |
10.00 | — | √ | √ | √ | √ | √ | √ | √ |
12.00 | — | √ | √ | √ | √ | √ | √ | √ |
12.70 | — | √ | √ | √ | √ | √ | √ | √ |
Tolerance of OD
OD | usual(PA) | precision(PC) |
<4.76 | ±0.08mm | ±0.05mm |
4.76 ~ 8.00 | ±0.12mm | ±0.07mm |
>8.00 ~ 12.00 | ±0.16mm | ±0.10mm |
>12.00 | ±0.20mm | ±0.12mm |
Mechanical property
type | Tensile strength Rm/MPa | Yield strength ReL/MPa | elongation A/% |
Soft tube(MA) | 280-320 | ≥170 | ≥35 |
Hard tube(MB) | 320-350 | ≥200 | ≥25 |
Chemical composition %
element | C | Si | Mn | P | S |
cold rolled low carbon steel | ≤0.08 | ≤0.03 | ≤0.30 | ≤0.03 | ≤0.03 |
Cold rolled exceed Low carbon steel | ≤0.008 | ≤0.03 | ≤0.25 | ≤0.02 | ≤0.03 |



If clients have special requirement on the material, tube size, tube type, mechanical property,
length, packing conditions, Pls contact us free. if we can do,we will do it as customizing.
1) Are you a trading company and manufacturer?
Yes, we have have plant and trading company, we can deal business both, but do it as condition.
2) How can I get your prices?
Pls show us your target tube size (OD ,wall), material (steel grade),coating types( coating types on OD/ID
both), in coil or straight length tube(if length, how long per pcs?), quantity, packing requirement ,application
and specialy requirement. Then,we can send you an exact quotation within 24 hours.
3) What's your MOQ?
For common coating type and common size, MOQ is 1000kg ; for specially coatinf type or specialy size
need confirmed.
4) How can I get some samples to do quality approved?
After quotation confirmed, we can send some samples for testing, severl pieces tube are free,but big
quantity maybe charged and freight should be bear by client.
5) What about the leading time for mass order producing?
Usually, 7-10 days for material preparing and producing after order confirmed, and 7 days for shipment
booking and confirmed.15 days min for common size and type, special size and type need confirm.
6) Could the tube be customized for us?
Sure, we are professional supplier.when we confirmed and accept all your target requirement,we can
customize the tube as your target.
