0.7-23LPH, 16-1.5bar, Hydrazine Dosing Pump for Boiler
German brand, made in China.
PP dosing head, EPDM seals.
0.7-24L/h,16-1.5 bar.(4.56-152.2GPD, 232-22Psi)
German quality.
Hydrazine is an oxygen binding agent used in service water applications, primarily in steam generating
systems. It is a carcinogenic substance that requires particular care and attention when handling.
It is safe to assume that the triggering threshold of hydrazine will not be exceeded in sealed and gas-tight
systems if used properly.
Tasks and requirements
Metering of oxygen binding agent to the boiler feed water to prevent oxygen corrosion in the boiler area.
Operating conditions
Fully desalinated potable water
Continuous operation
Application information
Proportional metering of oxygen binding agent depending on the boiler feed water
The 15 % concentrate is metered by a metering pump using a measuring unit into the metering tank and
is diluted with water to produce a 1 % metering solution
Measurement of the metering pump capacity during commissioning
| Product Name | Hydrazine dosing pump |
| Type/Series | CONC |
| Brand | German Brand |
| Made in | China |
| Structure | solenoid diaphragm |
| Capacity | 0.7-23L/h (4.56-152.2GPD) |
| Back pressure | 16-1.5bar (232-22Psi) |
| Liquid ends | PP head, EPDM/FPM seals |
| Power supply | 220V,100-230V,50/60Hz |
| Power consumption | 12W,16W,24W |
| Protection class | IP65 |
| Insulation class | F |
| Control type | manual,external contact, 4-20mA anolog |
| Packaging type | carton |
| Delivery time | within 1 week |
| Warranty | 1 year from delivery date |
We also have dosing pumps with other capacity&back pressure for your option.
Welcome your enquiry.
The CONC solenoid dosing pump is a microprocessor-controlled, short-stroke, solenoid-driven, diaphragm-type dosing pump for metering liquid, non-combustible media. It is popular to our customer for its precise design, reliable operation, good performance-cost ratio. It is widely applied to all kinds of chemicals dosing, with a good anti-corrosion performance of the liquid ends.
Highlights:
1.Solenoid-driven positive displacement dosing pump, compact, reliable & durable.
2.Capacity range from 0.7 l/h to 23 l/h, at a max. backpressure of 1.5 bar to 16 bar.
3.Multiple choices of liquid end materials for anti -corrosion purpose.
4.Stroke length is adjustable manually from 0 to 100%.
5.Various stroke frequency control modes on request:
3 constant metering frequencies manually: 100%, 50%, 25%.
Potential free contact input & 50%, 100% constant frequencies.
4-20mA input & 50%, 100% constant frequencies.
Liquid end material:
PP1=PP/EPDM seal
(PP2=PP/FPM seal(Viton®) not applicable for dosing hydrazine)
* All options are with bleeding valves.
CONC solenoid dosing pump:
Standard Accessories(foot valve+injection valve+2m PVC inlet hose+5m PE discharge hose)
CONC Dosing Pump Production Line:
| Type of packaging | carton |
| Size/weight for 1pc package | 33*28*19cm/4KG |
| Size/weight for 5pcs package | 35*30*100cm/21KG |
| Shipping method | Express,air,sea |
