Waste PET bottle recycling line
Application:
The equipment is suitable for washing crushing dryer material of PET bottle etc
Consideration for our customer we will design different line for our customer:
1: We provide different capacity for our customer: 200kg/h, 300kg/h, 500kg/h, and 1000kg/h.
2: According to your material, you may choose different device.
3: According to your country condition, you may choose full automatic line or semi-automatic line.
4: Our customer may purchase device based on his own condition.
5: We providing turn-key project for our customer.
Design-produce the machine-installment-testing.
6: Based on your workshop condition, our design always matched to your workshop mostly.
We sincerely wish our new products will bring win-win for both of our customer and us.
1,This PET bottle crushing, washing and drying production line can wash and recycle waste PET bottle flakes easily,which includes PE/PP labels, PVC labels, paper labels, HDPE cups, glue, mud, beverage leftover, oil, and scrap iron.
2, Equipment at the end of the washing line so that the completely dry flakes can be collected and packed directly after being washed.
3, the whole production line can be designed on the basis of how dirty the flakes are, and make sure of the quality of the final products.
4, Coordinating the production line with follow programmed work (granulating system), and it will make waste and dirty PET bottles to be the PET granule material and in order to producing new PET bottles. The material from this equipment can be put into the granulating machine directly.
5, we can supply production line with capacity from 100kg/h to 3000kg/h.
The whole equipment includes parts:
NO |
ITEM |
DESCRIPTION |
SELECTIVITY |
1 |
Prewasher |
Remove the solid impurity which are water insoluble, such as hand stone, sand, etc. It can also wash bottles' surface. |
Optional |
2 |
Bale Breaker |
It is used in large capacity recycling line, and bottles are compressed in bale. |
Optional |
3 |
Belt Conveyer |
Including the metal detector. |
Necessary |
4 |
Label Remover |
Label removing efficiency more than 98% |
Optional |
5 |
Manual Select Plateform |
Made according to workers' height, supply a suitable plate for selecting the left lables or some other impurity. |
Optional |
6 |
Belt Conveyer |
Conveying the bottles into crusher. |
Necessary |
7 |
Crusher |
With water, the materials of the blade adopt SKD-II or 9CrSi. It has a function of prewashing too. |
Necessary |
8 |
Screw Feeder |
Conveying the flakes into friction washer. |
Optional |
9 |
Friction Washer |
Scrubbing material in high-speed with water. |
Optional |
10 |
SCrew Floating Washer |
Remove few remand paper, sand, label from material based on different density. |
Optional |
11 |
Screw Feeder |
Conveying the flakes into hot washer. |
Necessary |
12 |
Hot Washer |
High temperature stirring washing with caustic soda. Water can be heated by steam or electric. |
Necessary |
13 |
Screw Feeder |
Same as Item 8. |
Necessary |
14 |
Friction Washer |
Same as Item 9. |
Necessary |
15 |
Screw Floating Washer |
Same as Item 10. |
Necessary |
For the more details, please do not hesitate to ask us.
