Product Details
Condition: | New | Type: | Natural Circulation | Usage: | Industrial |
Structure: | Water Tube | Pressure: | Low Pressure | Style: | Horizontal |
Fuel: | Coal-fired | Place of Origin: | Henan, China | Brand Name: | DINGSHENG |
Model Number: | YGL-500MA-Y(Q) | Output: | Hot Water | Dimension(L*W*H): | 1650*2850MM |
Weight: | 6700KG | Certification: | ISO9001-2008 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
List of Boiler Manufacturers Oil Heater Boiler -chain grate stoker boiler -extruded Shape
Rated Thermal Power : 120-1400kw
thermal efficiency: 65%-92%
rated steam pressure : 0.6mpa,1.0mpa
maximum working temperature:320 degree,350degree
oil boiler capacity: 0.07 m3-200m3/h
circulating oil : 12.5-100m3/h
piping connection diameter: 50-125DN
system installed capacity: 8-35kw
boiler diameter: 1215-2200 m
boiler height: 2310-5100m
boiler weight: 2500-7300kg
Application of thermal oil heater industry.
1.Chemical Industry --polymerization industry ,oil industry, reaction tank,distillation ,enrichment
2. Plastic industry ---plastic and squeeze to finalize the design
3. Textile industry --resin stenters ,dyeing machine and the dry room ,high temperature machine,
roller.
4.Rubber industry -rubber vulcanization heating
5.Food industry --cooking dry,vegetable oil refining
6.Wood industry --heating to finalize the design of chipboard sandwich plate ,wamu board,fiber
7.Paper industry-multi-layer cardboard of packed carton box ,dying and desiccation
8.Others-heating of metal electroplating slot ,coating condensation ,drying ,distillation of
pharmaceutical industry, reduction ,concentration,dehydration,airconditioning industry.etc
PARAMETERS:
Fuel(Gas)Organic Heat-Carrier Boiler | ||||||||||
Type | YYW0.24(20) | YYW0.35(30) | YYW0.6(50) | YYW0.9(75) | YYW1.2(100) | YYW1.5(235) | YYW1.8(150) | YYW2.5(200) | YYW3(250) | |
Rated thermal | 0.24 | 0.35 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.5 | 3 | |
Thermal | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | |
Rated Steam | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
Maximum working | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | |
Capacity | 0.21 | 0.25 | 0.28 | 0.44 | 0.64 | 0.793 | 1.25 | 1.76 | 1.9 | |
Circulating oil | 40 | 40 | 80 | 80 | 80 | 100 | 100 | 200 | 200 | |
Piping connection | 100 | 100 | 100 | 100 | 125 | 125 | 125 | 150 | 150 | |
System installed | 14 | 14 | 22 | 22 | 40 | 40 | 40 | 66 | 70 | |
Size | Diameter | 1016 | 1016 | 1216 | 1416 | 1716 | 1716 | 2000 | 2000 | 2320 |
Height | 2050 | 2350 | 2450 | 2900 | 3300 | 3900 | 4100 | 5100 | 5300 |
