LED Display Screen for Sports Event Commercial Advertising

FOB Price

USD $1,050 - $1,200 / Square Meter

1 Square Meter(Min.Order)

Supply Ability 3000 Square Meter / Square Meters per Month
Port Shenzhen
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Guangdong, China	Brand Name:	ZXSheng	Model Number:	stadium sports event led display
Usage:	Outdoor	Tube Chip Color:	Full Color	Display Function:	Video
Pixels:	10mm	Screen Dimension:	Customized

Packaging Details

Wooden case & Flight case, 2 cabinets in one case generally

Product Description

Specifications

stadium sports event led display
1.Low-carbon,pro-environment
2.High refresh rate,brightness
3.CE& ROSH
4.Good service

stadium sports event led display

LED display outdoor---10mm Real Pixel
Pixel Paramter	Pixel pitch	10mm
	LED configuration	1R1G1B(LED-lamp)
	LED packadge mode	DIP 346
	Pixel density	10000
Module Parameter	Module size	160mm*160mm
	Module resolution	16*16
	Module Material	Black PC cover, PC base
	Mask	Soft mask
	Drive method	1/4 scan constant current driving
Cabinet Parameter	Cabinet size	960mm960mm170mm/(115mm without back door)
	area	0.9216sqm/cabinet
	pixel density by area	10000 pixels/sq meter
	Cabinet weight	65kg
	Cabinet resolution	96 * 96pixels
	Cabinet material	Steel
	Cabinet Thickness	Standard Canbinet135+35mm
	Cabinet Color	Black, other color
	LOSE control rate/blind spot ratio	less than 0.03%, the discrete distribution
Screen parameters	Max. power consumption	750W
	Ave. power consumption	325W
	Best viewing distance	10-150m
	Brightness	≥ 6000CD/sqm
	Best viewing angle	hor. 110° ver, 70°
	Frame frequency	≥ 60Hz/s
	Operation voltage	AC220V± 10%/AC380V± 10%, 50hertz± 10%
	Front color	black, rubber
	Protection	IP65
	Refresh rate	adjustable from 10Hz to 3000Hz
	Grey Level	256 levels
	Grey scale	16K
	Life time	100, 000 hrs
	Display color	281 trillions
	Environmental temperature	-20° C~+60° C
Control system	System Software	Windows98/XP/2000/vista
	Input signal	Video: PAL/NTSC optioned. VGA, Svideo, DVD, TV
	LED driving method	1/4 static scan; constant current drive
	Image refresh rate	300 hertz
	brightness adjustment	100 level
	Control distance	100 m by net line; Optical fiber transmission

Certifications:

Company Profile

Shenzhen Oscarled Opto Co., Ltd.

Shenzhen Oscarled Co., Ltd. is a professional LED display manufacturer in China. Our company is engaged in research, production, sale and technical service together. We have rich experience in LED display industry. As one of the outdoor full color LED display and indoor LED screen leading manufacturers, we have professional R&D teams and after-sales service teams.
Our products include taxi top led display ,outdoor full color LED displays, indoor full color LED displays, dual-color and single color LED displays, stage background LED screens, rental LED screens, traffic LED signs, curtain LED displays and so on. Our LED displays are widely used for advertising billboards, banks, retailers, hospitals, schools, expressways, governments, etc.

We have won praise from domestic and overseas markets for our top-class quality and competitive products. Producing high quality, high technical and lower price LED display screens for our customers will still be our development goal.
