Outdoor Commercial LED Display Screen of P10

Name: Outdoor Commercial LED Display Screen of P10
Brand: ZXSheng
SKU: 105449333
Availability: InStock

US$ 1,000 - 1,200 MOQ: 1 Square Meter

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ZXSheng

Model Number:

P10 led display screen

Shenzhen Oscarled Opto Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ZXSheng

Model Number P10 led display screen

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels 10mm

Screen Dimension 6400x4800mm, or customized

Specifications

P10mm Outdoor LED Display Screen:
1.P10 clear LED video board
2.High brightness, good price
3.CE& ROSH
4.Short lead time

List	Item	Description
1	Pixel Pitch	10mm
2	Module Size	160*160mm
3	Pixel Density	10000/sqm
4	Pixel composition	1R1G1B
5	LED Type	DIP346
6	Module Resolution	16*16
7	Power Consumption of Module	24W
8	The Optimum Viewing Distance	10m
9	The Optimum Viewing Angle	110°
10	Maximum Power Consumption	920W/sqm
11	Cabinet Size	640*480mm
12	Cabinet Resolution	64*48
13	160*160mm	65Kg Water-proof
14	Driving Method	1/4 Scan Constant Current Driving
15	Frame Frequency	≥60Hz/s
16	Refresh Rate	≥360Hz/s
17	White Balance Luminance(CD/sqm)	≥5000cd/sqm
18	Operating Environment Temperature	-20°C—60°C Optional
19	Operating Voltage	220°C±10% or 110°C±10%
20	Grey Scale	Display Colors≥16.7M(Synchronized)
21	Brightness Adjustment	256 grades of each color(R.G.B)can be adjusted manually and 8 levels of each color can be adjusted automatically
22	Input Signal	RF,S-Video RF, S-Vido, RGB, RGBHV, YUV etc.
23	Control System	PCTV non-liner editting card+DVI display card+main control card+optic fiber transmission(Optional) or video dealer
24	Average No Failure Time	>5000 hours
25	Life-span	>100000 hours
26	Out-of Control rate	<0.0001
27	Transmiting Distance	Internet cable:< 100m, the distance will add 100m if add one signal collector. Optic fiber: ≤20Km(single module),≤500m(modules)
