1.High Quality of LED chip.
2.Antistatic,waterproof,dustproof,antiseptic,antiflaming.
3.Lowest rate of blind spots.
4.Advanced producing technology.
5.Uniformity of brightness and color.
6.High pixel, smooth and clear.
7.Wide visible angle:good horizontal nd vertical angle.
8.Easy maintenance: single point maintenance and low cost.
P7.62 SMD3in1 3528 Indoor full color display parameter
P7.62 SMD3528 Indoor full color Parameters | |
Mode |
P7.62 |
Pixel Pitch |
7.62mm |
LED Configuration |
1R1G1B |
LED standard |
SMD3in1-3528 |
LED Density |
17222dots/Square meter |
Module Size |
244mm*244mm |
Red LED |
620nm; 150-200mcd |
Green LED |
525nm;260-330mcd |
Blue LED |
467nm;55-65mcd |
Luminance |
≥ 1500CD/Square meter |
Optimal Viewing Distance |
8m--30m |
Horizontal View Angle |
≥140 angle |
Vertical View Angle |
≥110angle |
Display Colors |
1024*1024*1024=1073741824Kinds |
Cabinet |
Punch molding with thick aluminum of 2mm |
Driving Mode |
1/8 Scanning |
Contrast |
1000:1 |
Storage Humidity |
-40°C-+85°C |
Working Humidity |
-20°C-+40°C |
Relative Humidity |
10%-95%RH |
AC Working Voltage |
220V±10% |
Average Power Consumption |
300W/Square Meter |
Max Power Consumption |
≤880W/Square Meter |
Refresh Rate |
≥360Hz |
Frame Frequence |
=60Hz |
Malfunction Dot Rate |
1/10000;2-3/10000 after one year |
Brightness Adjustment |
Software that adjust brightness according to the environments’ brightness |
Average Trouble Free Time |
≥10000 hours |
Life Span |
≥100,000 hours |
Flatness |
space between modules<1mm |
Uniformity |
Brightness of module is uniformity and strong |
Blind Spot Rate |
<0.0001 |
Electric Protection |
Protect from over current, short circuit,open circuit and overvoltage |
External Protection |
Waterproof, dustproof,antiseptic,antiflaming. |
Remarks |
Color rate of the LED brightness is seriously required in order to reach the best white balance |
Packing
LED modules: cartons
LED display:wooden case or flight case
Shipping:
By sea,by air,by DHL, by UPS, by TNT ect.
Trade Terms
1.Payment:T/T,30% deposits before production,70% balance to be paid before dleiverying
2.Shipping freight are quoted under your requests
3.Shipping port:ShenZhen,Mainland China
4.MOQ:1PC
Our Service
1)Your inquiry related to our products or price will be replied in 24hrs
2)OEM&ODM,any your customized lightings we can help you to design and put into product
3)Distributoership are offered for your unique design and some our current models
4)Protection of your sales area,ideas of design and all your private information
5)Top Quality+Reasonable Price+Responsible After Service=Successful & Win
Many certificates like 3C, CE, FCC, ROHS have been achieved.
Before we offer you best quotation, we'd to confirm some details if you don't mind:
1. What's the size of screen, cabinet you prefer?
2. What's the best viewing distance with your project?
3. What's the color of cabinet you need? Any logo on back of cabinet?
4. When do you need to get goods? Is this urgent?
5. Any special requests? Such as video processor,hanging bar,flight case for package? Please advise it as well.
