50 Ampere Normal Open dc Contactor
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
DY
Model Number:
ZLJM-50A/60V
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
DY
Model Number
ZLJM-50A/60V
Electricity Type
DC
Number of Pole
1
Phase
1
Main Circuit Rating Voltage
Other, 60VDC
Main Circuit Rating Current
Other, 50A
Model No. |
ZLJM-50A/ |
Contact material |
Ag Alloy |
Contact Rating |
50A 48VDC |
Coil rated voltage |
48VDC |
Pick-up Voltage |
(85~110)%V of coil rated voltage |
Drop-out Voltage |
(10~40)%V of coil rated voltage |
Coil maintain current (+20℃) |
<0.25A |
Contact Pressure Drop |
At 50A, ≤50mV |
Insulation Resistance |
Min. 100MΩ at 500VDC |
|
Dielectric Strength (Between Insulated Electric Parts) |
1000VAC 50 HZ/60 HZ (1 minute) |
Operate Time |
Max. 30mSec. |
Release Time |
Max. 30mSec. |
Ambient Temper |
-40℃~+60℃ |
The shocking of fixed point |
(10~200)HZ,Acceleration≤3.5g |
Shocking |
(60~100) times/min,Acceleration≤4g |
Ambient temperature |
-25℃~+60℃ |
Mechanical Life |
100,000 Operations (no load) |
Electrical Life |
1,0000 Operations (at rated load) |
