DC CONTACTOR N.C. TYPE BZJ-400A.S
- 2 Piece / Pieces per Month
- Shanghai/Ningbo
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | DY | |
| Model Number | BZJ-400A.S | Electricity Type | DC | |
| Main Circuit Rating Voltage | Other, 12VDC-120VDC | Main Circuit Rating Current | 400a |
Product Description
Specifications
DC CONTACTOR N.C. TYPE BZJ-400A.SSPST-NC Contact Arrangement
Certificate: UL, TUV, CCC,ROHS
DC CONTACTOR N.C. TYPE BZJ-400A.S
Model No. | BZJ-400A.S |
Contact Arrangement | 1D (SPST-NC) |
Contact Material | AgCdO12 |
Contact Rating(at Resistive Load) | 400A 48VDC 400A 250VAC |
Max. Switching Voltage | 60VDC,250VAC |
Max. Switching Power | 100000VA |
Endurance of Over Loading Current7Ie/10S | 2800A/10S |
Coil Rated Voltage | 12V,24V,48V,60V,72V,120VDC etc. |
Pick-up Voltage | 40-70% of coil rated voltage |
Drop-out Voltage | 5-30%V of coil rated voltage |
Contact Pressure Drop | At most 30mV when 100A |
Insulation Resistance | Min. 100MΩ at 500VDC |
Dielectric Strength (Between Insulated Electric Parts) | 1000VAC 50 HZ/60 HZ (1 minute) |
Operate Time | Max. 50mSec. |
Release Time | Max. 50mSec. |
Ambient Temperature | -40oC~+60oC |
The shocking of fixed point | (10-200)HZAcceleration≤3.5g |
Shocking | (60-100) time/minuteAcceleration≤4g |
Mechanical Life | 100,000 Operations (no load) |
Electrical Life | 10,000 Operations (at rated load) |
