Nmrv Manufacturer Worm Gear Speed Reducer

Aluminum alloy speed gearbox/ worm gear box/ gear reducer NMRV025-150 is made by Nayuan Transmission Machinery has many advantages compared with the speed reducer made by other company. Our company can offer two models of speed reducer, such as single step worm gear reducer and double step worm gear reducer. Nayuan Transmission adopts high quality aluminum alloy die casting box to manufacture worm gear reducer. Our worm gear speed reducer features in light weight, good appearance, compact structure and rust-proof. Nayuan can provide worm gear speed reducer with various reduction ratios for the customers to choose.

Structure Features

Aluminum alloy speed gearbox/ worm gear box/ gear reducer  NMRV025 030 040 050 63 75 90 110 130 150

1. Made of high quality aluminum alloy, light in weight and non-rusting

2. Large in output torque

3. Smooth in running and low in noise, can work long time in dreadful conditions

4. High in radiating efficiency

5. Good looking in appearance, durable in service life and small in volume

6. Suitable for Omnibearing installation

Detail Accoessries
Type: Worm Gear Speed Reducer
Model: NMRV025, 030, 040, 050, 063, 075, 090, 110, 130, 150
Ratio: 1:5,7.5,10,15,20,25,30,40,50,60,80,100
Color: Blue/Silver or customer request
Housing: Aluminum alloy and casting iron
Packing: Carton/Wooden case
Bearing: C&U Bearing
Seal: NAK , SKF
Warranty: 12 month
Input Motor power: 0.06kw, 0.09kw, 0.12kw, 0.18kw, 0.25kw, 0.37kw, 0.55kw, 0.75kw, 1.1kw, 1.5kw, 2.2kw, 3kw, 4kw, 5.5kw, 7.5kw, 11kw, 15kw
Usages: Industrial Machine: Food Stuff, Ceramics ,CHEMICAL, Packing ,Dyeing ,Wooding working ,Glass
IEC Flange: 56B5, 56B14, 63B5, 63B14, 71B5, 71B14, 80B5, 80B14, 90B5, 90B14, 100B5, 100B14, 112B5, 112B14, 132B5, 160B5
Lubricant: Synthetic & Mineral

Gearbox Materials

1. Housing: die-cast aluminum alloy (Housing size: 025-090); cast iron (Housing size: 110-150)

2. Shaft: 20Cr, carbonize and quencher heat treatment make the hardness of gear tooth surface up to 56-62 HRC, retain carburization layer’s thickness between 0.3-0.5mm after precise grinding

3. Worm Wheel: Wearable bronze alloy

Surface Painting

For Aluminum Alloy Housing:

1. Shot blasting and special antiseptic treatment on the aluminum alloy surface

2. After phosphating, paint with blue or sliver.

For Cast Iron Housing:

Before paint with blue or sliver, need paint with red antirust pain first.

Aluminum alloy speed gearbox/ worm gear box/ gear reducer  NMRV025-150

Please read before use

1. Load condition

2. Speed of rotationi or speed ratio (combination with combine speed reducer can get extra low outputing rotational speed)

3. Work circumstance (temperature, humidity, corrosion etc.)

4. Space of installation

Since Nayuan Transmission Machinery has abundant experience in offering OEM service and all the workers have worked in this industry more than three years, our company can deliver the items to you in 7-15 workdays after receiving 30% deposits.

Aluminum alloy speed gearbox/ worm gear box/ gear reducer NMRV025-150 is guaranteed with superior quality and our technicians will provide excellent technological support and the 24-hour self-service center is also available.
