High Quality Craft Worm Gearbox Made of High Quality Aluminum Alloy

Excellent craft worm gearbox made of high quality aluminum alloy

Structure Features

1. Made of high quality aluminum alloy, light in weight and non-rusting

2. Large in output torque.

3. Smooth in running and low in noise, can work long time in dreadful conditions

4. High in radiating efficiency.

5. Good looking in appearance, durable in service life and small in volume

6. Suitable for Omnibearing installation.

Gearbox Material

1. Housing: die-cast aluminum alloy (Housing size: 025-090); cast iron (Housing size: 110-150).

2. Shaft: 20Cr, carbonize and quencher heat treatment make the hardness of gear tooth surface up to 56-62 HRC, retain carburization layer’s thickness between 0.3-0.5mm after precise grinding.

3. Worm Wheel: Wearable bronze alloy.

Surface Painting

For Aluminum Alloy Housing:

1. Shot blasting and special antiseptic treatment on the aluminum alloy surface.

2. After phosphating, paint with blue or sliver.

For Cast Iron Housing:

Before paint with blue or sliver, need paint with red antirust pain first.

Excellent craft worm gearbox made of high quality aluminum alloy

Please read before use

1. Load condition

2. Speed of rotationi or speed ratio (combination with combine speed reducer can get extra low outputing rotational speed)

3. Work circumstance (temperature, humidity, corrosion etc.)

4. Space of installation

Since Nayuan Transmission Machinery has abundant experience in offering OEM service and all the workers have worked in this industry more than three years, our company can deliver the items to you in 7-15 workdays after receiving 30% deposits.

Our  worm gearboxes are guaranteed with superior quality and our technicians will provide excellent technological support and the 24-hour self-service center is also available.

Our main products are gearbox, reducer, gear, worm, worm gearbox, worm reducer, speed gearbox, transmission, drive part, motor, coupling, planetary gearboxes, helical gearboxes, Sprockets Gears and Racks, variators, Timing Belt Pulleys and v pulleys and sheaves, shaft collars and motor bases, Chains and Belts, shaft and agricultural gearboxes, Bushes and Hubs Couplings, screw jacks and housing. Kindly, if you need Gearbox, please send us the Model, Ratio and Quantity. Then I will give you the best offer
