Specifications
QLN Brand Farm Tractor1. Brand engine
2. Fitted implements
3. Hydraulic steering, enforced PTO
4. One year warranty
Henan Qianli Company is specialized in Agricultural Equipments Manufacturing!
The main produce are wheel tractors 20hp to 145hp ,walking tractors 8hp to 20hp, and wide range of farm implements.
We are open to distributorship, and looking forward to establish mutual benefit cooperation with your esteemed company!
+ =
♦Advantages and Characteristics of wheel tractor
1. Equipped with famous brand engine YTO/YUCHAI, with good performance, low fuel consumption and high economic efficiency.
2. Beautiful engine hood , Streamlined appearance.
3. 6,8,21 spline PTO( Power Take Off).
4. Rotation speed of PTO: 540/760r/min.
5. Hydraulic steering.Dual-stage clutch.
♦Specification of QLN504
| Model | QLN 504 |
| Drive type | 4*4 |
| Engine | |
| Engine model | YT4A2 |
| Capacity of fuel tank(L) | 43 |
| Rated speed (r/min) | 2300 |
| Engine power (kw) | 36.7 |
| Rated fuel consumption (g/kw·h) | ≤242 |
| Transmission | |
| Clutch | Single disc /dry type /dual stage |
| PTO Speed(rpm) | 540/760 (commonly used) |
| Gearshift | F8+R4 shuttle gears |
| Hydraulic system | |
| Hydraulic output valve | one group |
| Three point linkage | |
| Category of 3-point link | categoryⅡ |
| Lifting capacity(at point of 610mm)KN | 9.2 |
| Technical parameter | |
| Dimension( L*W*H) mm | 3615*1750*2150 |
| Wheel base(mm) | 1990 |
| Track base(mm) front/rear wheel | 1400/1300 |
| The smallest clearance(mm) | 325 |
| Front /rear tyre | 8.3-20/12.4-28 |
♦Our honours: Since its inception, we have always operated with principle of positive,innovative and open up.
So, after years of develop and hard work,our company has received lots of honors we deserve.
♦We have oppornity to participate in the exhibitions,and attracts many foreign customers.Our worknet has spread all over the world.
Our products have been exported to many other countries, such as Romania, Russia, Ukraine, Tanzania, Thailand, Australia, etc.
♦Our products:Different kinds of color and styles,we can also customized for you.Our professional technicians and workers guarantee the quality and maintenance of pruducts.
♦Details of our products,they give you a much clear comprehension about QLN tractors.We concentrate on quality of products, including every details.
♦We are specialized in tractors, but we can offer you a one-step service,
so there are a wide range of farm implements we supply.
If you have any interests in our products, pls feel free to contact us!!
Wish you a sunny day!!
