Specifications
Paper cup sleeve wrapping machine(YT-LH Model)
matching equipment of paper cup Machine
forming&wrapping sleeve around pape
Paper cup sleeve wrapping machine
YT-LH model Automatic Paper cup(bowl)direct paper sleeve forming&wrapping machineis developed and designed according to the market requirment,It is a matching equipment of Pper Cup /Bowl Forming Machine,with the function of photosensor detecting,failure alarming and counting.It is available for forming and wrapping direct-style sleeve around the paper cup/bowl against the procedure of automatic paper feeding,sealing (Ultrasonic system seal sleeve side),glue spraying,auto feeding cup/bowl and wrapping sleeve around the cup,collecting.. This model has advanced technology ,reliable design,easy maintenance and operation. The direct style sleeve paper cup/bowl is an ideal paper container for Hot Drinks
P.S: We can design and develop the mould esecially for you as per the orginal cup/bowl samples.
Technical data sheet
| Model | YT-LH |
| Sleeve size | 6-20oz for cup, 20-50oz for bowl |
| Raw material | PE coated paper, paper board (200-350gsm) |
| Productivity | 40-50pcs/min |
| Power Source | 380V, 50Hz or other required |
| Total Power | 4kw |
| Weight | 1100Kg |
| Dimension | 2250*1250*1750mm |
