Home > Manufacturing & Processing Machinery > Metallurgy Machinery > CNC-635Z New Design of Wire Rotary Machine in 2014,Spring Forming Machine
CNC-635Z New Design of Wire Rotary Machine in 2014,Spring Forming Machine
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
WNJ
Model Number:
CNC-635Z
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Zhejiang Integrity Enterprises Wire Rotary Spring Machine Price With Wire RotationNegotiableMOQ: 1 Set -
CNC-625Z Wire Rotary Spring Machine With Wire RotationNegotiableMOQ: 1 Set
-
WNJ- Leader of Spring Machine Manufacturer in China CNC-1250 12 Axis Spring MachineryNegotiableMOQ: 1 Set
-
Zhejiang Shaoxing Machinery Solid Professional CNC Spring Automatic Forming MachineNegotiableMOQ: 1 Set
-
CNC-650 5 Axis Second Hand CNC Spring Manufacturer Machine in WNJNegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
WNJ
Model Number
CNC-635Z
After-sales Service Provided
Engineers available to service machinery overseas
| Item Name | CNC-635Z New Design of Wire Rotary Machine in 2014 |
| Style | CNC-635Z |
| Color |
Grey/Blue |
| Wire Diameter (mm) | Φ1.5~Φ3.5 |
| Total Power (KW) | 13 |
| Number of Axes | 5 axis |
Number of The Wire Feed Wheel |
3 pairs |
| Servo Motor of Wire Feed | 5.5KW |
| Servo Motor of Rotary Wire | 5.5KW |
| Servo Motor of Rotary Mandrel | 1KW |
| Servo Motor of Curved Shaft | 1KW |
| Space Axis Motor(KW) |
4.5 |
| Main Machine(L*W*H) | 2100*1300*1800 |
| Net Weight of Machine (KG) | 2700 |
| Power | Three phase 380V.AC.50HZ |
PRODUCT PARAMETERS
- Equipped with the computer-controlled system imported from Taiwan and servo motor imported from Japan .
- This machine is for camdesign,set up spring with high speed and accuracy.And with stable good enough .
- Wire feed with the function of rotary wire,so it is easy to adjust .
- Computer interface displayed in Chinese and English which makes the operation easy .
- It is suitable for producing double torsion spring, straight spring, pagoda-shaped compression spring, rectangle spring, swirl spring and other different spring and special-shaped spring .
OUR SERVICE
- Two-years (computer ) &one-year (mechanical) warranty.
- Permanent technical service .
- One week free training with accommodation and food.
- Engineer can be sent aboard for installation, debugging and training.
MAIN PRODUCTS
COMPANY INFORMATION
CERTIFICATION
PARTNERS
AGENTS
FAQ
- What is your machine controller and motors?
- Controllers are imported from Hust, Taiwan. Motors from Sanyo,Janpan.
- Can you offer training in our plant?
- Basically, we have sales and service teams in Euro, Turkey, Korea,Japan, South American, India. If you are out of these countries, our enginner will be sent to your place for training if you need.
- How many years you exported? Do you have CE?
- Definitely, we have exported spring machines in past 9 years, and all of the machines have CE certificates.
