Help Center2WB 2/2 Way Direct Action Stainless Steel Solenoid Valve (air/water/steam) Water Valve
Related Products
-
2WBF 2/2 Way Direct Action Stainless Steel Solenoid Valve Water Valve ISO9001NegotiableMOQ: 1 -
PU220 2/2 Way Direct Action Brass Solenoid Valve (water,air,oil,gas) Water Valve ISO9001NegotiableMOQ: 1
-
PU225 2/2 Way Pilot Type Brass Solenoid Valve (water,air,oil) Water Valve ISO9001NegotiableMOQ: 1
-
US-15 2/2 Way Pilot-operated Steam Solenoid Valve (water,air,steam) Water ValveNegotiableMOQ: 1
-
2P025 2/2 Way Solenoid Valve Plastic Body (water,air,oil,gas) Water ValveNegotiableMOQ: 1
Specifications
Stable qualityCompetitive price
Fast delivery
Plastic package will keep safty when use
Popular with customers
1. Structure in sliding column mode: good tightness and sensitive reaction;
2. 2WB series solenoid valve with stainless steel body ,media can be water , weak acid & alkali. ,
3. Thread size range from G1/8’’ to G3/8'’, orifice size range from 1.2mm to 4mm.
3. Din connector type and flying leads type, anti-explosion and anti-water coil are available. With the stable function and extensive application, 2W valve is popular with customers, especially in the water treatment system is widely used .
4. It could start with no voltage.
5. The structure of flat diaphragm will extend it's life.
6. Plastic package will keep safty when use.
Port size from 1/8'' to 3/8'', direct acting and normally closed.
- Specification
Model |
2WB30-06 |
2WB30-08 |
2WB40-10 |
2WB160-10 |
2WB160-15 |
2WB200-20 |
2WB250-25 |
2WB350-35 |
2WB400-40 |
2WB500-50 |
Orifice size |
3 |
4 |
16 |
16 |
20 |
25 |
35 |
40 |
50 |
|
Port size |
1/8’’ |
1/4’’ |
3/8’’ |
1/2’’ |
3/4’’ |
1’’ |
11/4’’ |
11/2’’ |
2’’ |
|
KV valve |
0.25 |
0.6 |
4.8 |
12 |
24 |
29 |
48 |
|||
Working medium |
Water, weak acid & alkali |
|||||||||
Operation |
Direct Acting |
|||||||||
Acting type |
Diaphragm type |
|||||||||
Working pressure |
0-1.0MPa |
0-0.7Mpa |
||||||||
Medium temperature |
NBR: -5~80°C: EPDM: -5~120°C; VITON: -10~150°C; SI: -15~150°C |
|||||||||
Working voltage |
AC380V,220V,110V,36V,24V DC220V,110V,36V,24V,12V |
|||||||||
- How to order
Packaging: Carton (or according to customers' requirements)
Loading port: Guangzhou / Shenzhen Seaport
Delivery time: 7-15 days (Depend on your qty)
Sample: Available with freight collected
