Help Center2W025 High Pressure 2/2 Way Direct Action Smaill Orifice Solenoid Valve (air/water/steam) Water Valve
Related Products
-
2WB 2/2 Way Direct Action Stainless Steel Solenoid Valve (air/water/steam) Water ValveNegotiableMOQ: 1 -
2WBF 2/2 Way Direct Action Stainless Steel Solenoid Valve Water Valve ISO9001NegotiableMOQ: 1
-
PU220 2/2 Way Direct Action Brass Solenoid Valve (water,air,oil,gas) Water Valve ISO9001NegotiableMOQ: 1
-
PU225 2/2 Way Pilot Type Brass Solenoid Valve (water,air,oil) Water Valve ISO9001NegotiableMOQ: 1
-
US-15 2/2 Way Pilot-operated Steam Solenoid Valve (water,air,steam) Water ValveNegotiableMOQ: 1
Specifications
Stable qualityCompetitive price
Fast delivery
Plastic package will keep safty when use
Popular with customers
1. Structure in sliding column mode: good tightness and sensitive reaction;
2. 2W series direct acting solenoid valve with small orifice type, thread size range from G1/8’’ to G3/8'’, orifice size range from 1.2mm to 4mm.
3. Din connector type and flying leads type, anti-explosion and anti-water coil are available. With the stable function and extensive application, 2W valve is popular with customers, especially in the water treatment system is widely used .
4. It could start with no voltage.
5. The structure of flat diaphragm will extend it's life.
6. Plastic package will keep safty when use.
- Specification
Model |
2W025-06 |
2W025-08 |
2W040-10 |
2WH012-06 |
2WH012-08 |
2WH020-10 |
Port Size |
G1/8" |
G1/4" |
G3/8" |
G1/8" |
G1/4" |
G3/8" |
Orifice Size |
2.5 |
4.0 |
1.2 |
1.2 |
2.0 |
|
CV Value |
0.23 |
0.60 |
0.05 |
0.05 |
0.15 |
|
Working Medium |
Air,Water,Oil,Gas |
|||||
Motion Pattern |
Direct acting |
|||||
Type |
Normally Closed |
|||||
Working-pressure |
Air,Water,Oil,Gas: 0~0.7MPa |
Air, Water, Oil:0~2.0MPa |
||||
Max. Pressure Resistance |
1.0MPa |
3.5MPa |
||||
Operating temperature |
NBR for-5-80oC and EPDM,VITON for-5-150 oC |
|||||
Voltage Range |
±10% |
|||||
Material of Body |
Brass or Stanless steel |
|||||
Material Oil Seal |
NBR,EPDM,VITON or SI |
|||||
- How to order
Packaging: Carton (or according to customers' requirements)
Loading port: Guangzhou / Shenzhen Seaport
Delivery time: 7-15 days (Depend on your qty)
Sample: Available with freight collected
We are professionally engaged in manufacturing, exporting & supplying compressed air & pneumatic components, air tools & accessories in industrial and process automation.
Factory: a management system in good order.
Plant: Nice and clean.
Over 10 years' production experience;
Strong technic developing & customization capacity for different requirements.
Main products: air preparation, solenoid valve, cylinder, ect.
High quality
Competitive price
Fast delivery
Starting with no voltage
Plastic package will keep safty when use
Popular with customers
Customization is available.
