Help CenterDouble Acting Pneumatic Air Cylinder SDA Series
Related Products
-
Rotary Table Rack Pinion Pneumatic Cylinder; Pneumatic Air Cylinder MSQ SeriesNegotiableMOQ: 1 -
Tri Rod Cylinder; Pneumatic Air Cylinder MGP SeriesNegotiableMOQ: 1
-
Standard Pneumatic Cylinder ISO6431 DNC Series China ManufacturerNegotiableMOQ: 1
-
Standard Double Action Pneumatic Air Cylinder SU SeriesNegotiableMOQ: 1
-
Standard Double Action Pneumatic Air Cylinder SC SeriesNegotiableMOQ: 1
Specifications
Using seals from Parker ,Japan and Korea,ensure the working ability and life span.Customerization (non-standard) available
A brief description of the product and advantage
Using seals from Parker ,Japan and Korea,ensure the working ability and life span.
Customerization (non-standard) available
Specifications
Double Acting thin compact cylinder
SDA series compact cylinder design made for the Asian market, the bore from 12mm to 100mm is optional. As to the acting type have double acting, double adjustable acting, single extend acting, single return acting etc. The rod side teeth within conventional-shaped teeth, outer teeth, toothless three kinds of connections. The crash pads buffer types effectively reduce the impact on the cover.
Double Acting thin compact cylinder
Bore(mm) |
12 |
16 |
20 |
25 |
32 |
40 |
50 |
63 |
80 |
100 |
|||
Working Medium |
Filtered compressed Air |
||||||||||||
Motion Pattern |
Double Acting |
||||||||||||
|
Single Acting Extrusion Type Single Acting Drawing-in Type |
|
||||||||||||
Compression Pressure |
15 bar |
||||||||||||
Max. Operating Pressure |
Double-acting Type |
1~9 bar |
|||||||||||
Single-acting Type |
2~9 bar |
||||||||||||
Cushion Type |
Bumper |
||||||||||||
Operating Temperature |
5~60°C |
||||||||||||
Operating Speed Range |
Double-acting Type |
30~500mm/s |
30~350mm/s |
30-250mm/s |
|||||||||
Single-acting Type |
100-500mm/s |
- |
|||||||||||
Joint Pipe Bore |
M5*0.8 |
1/8" |
1/4" |
3/8" |
|||||||||
How to order
Packaging: Carton (or according to customers' requirements)
Loading port: Ningbo Seaport
Delivery time: 10-30 days (Depend on your qty)
Sample: Available with freight collected
Using seals from Parker ,Japan and Korea,ensure the working ability of Air Cylinder and life span.
By virtue of years of accumulated experience in various industries customer,we can design and develop all types of non-standard cylinders according to different customers requirements.
We are professionally engaged in manufacturing, exporting & supplying compressed air & pneumatic components, air tools & accessories in industrial and process automation.
Factory: a management system in good order.
Plant: Nice and clean.
Over 10 years' production experience;
Strong technic developing & customization capacity for different requirements.
Main products: air preparation, solenoid valve, cylinder, ect.
Customization is available.
