small water jet cutting machine
- 400 Set / Sets per Month
- Shanghai
- T/T
Product Details
Condition: | New | Machine Type: | Glass Cutting Machine | Production Capacity: | 400 sets |
Place of Origin: | Jiangsu, China | Brand Name: | Sunrise | Model Number: | CUX400-SQ3020 |
Voltage: | 480V | Power(W): | 20/32kw | Dimension(L*W*H): | 2.5m x 1.5m |
Weight: | 4190tons | Certification: | CE | Warranty: | OneYear |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Metal cutting machine:1, cut metal in thickness 150mm;
2,cut metal in smoothy edge;
3, high work efficiency;
4,save cost.
Model | SQ1313 | SQ2515 | SQ3020 | SQ4020 |
Processing scope | 1.3m×1.3m | 2.5m×1.5m | 3.0m×2.0m | 4.0m×2.0m |
Form of machine | Cantilever | |||
Runing speed | 0-10m/min | |||
Control system | AC servo system | |||
Control accuracy | ±0.02mm | |||
Cutting accuracy | ±0.1mm | |||
Max working pressure | 400Mpa(60000psi) | |||
Max.flow rate of UHP water | 3.8L/in | |||
Motor power of oil pump | 22kw/30kw | |||
Power supply | 380V 50HZ |
Sunrise watetjet machine is a kind of machine with all purpose and consummate capability, the special characteristic is cold cutting there's no heat generate during cutting, cutting range materials such as metal ,glass,rubber ,plastic ,ceramic tile ,timber,marble,granite etc.
Our water jet machine adopts parts and technology of America, it can be more reliable and we offer more resonable price.
Metal cutting machine:1, cut metal in thickness 130mm; 2,cut metal in smooth edge;3, high work efficiency;4,save produce cost.
waterjet machine can cut any metal or non-metal materials ,there is no heat generated during cutting
Granite cutting machine , high quality got CE certificate: 1,cutting granite in thickness 120mm; 2, smooth cutting edge.
