WATER JET CUTTER FOR GLASS ,CNC WATER JET
US$ 32,000 - 60,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
SUNRISE
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CNC UHP Waterjet,stone Cutting WaterjetUS$ 32,000 - 60,000MOQ: 1 Set -
High Pressure Water Cutting ,UHP WaterjetUS$ 32,000 - 70,000MOQ: 1 Set
-
UHP CNC Waterjet CutterUS$ 30,000 - 60,000MOQ: 1 Set
-
CNC Waterjet CutterUS$ 30,000 - 60,000MOQ: 1 Set
-
Waterjet Cutting CUX400-SQ3020US$ 30,000 - 60,000MOQ: 1 Set
Condition
New
Place of Origin
Jiangsu, China
Brand Name
SUNRISE
Model Number
SQ4020
Voltage
380V
Rated Power
22KW/30KW
Dimension(L*W*H)
4.0m*2.0m*0.15m
Weight
5100KG
Certification
CE/SGS
Warranty
ONE YEAR
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.widely cut metal.galss.stone .foam etc.2.cutting thickness:1mm-150mm
3.Working pressure:320-400Mpa
4.No HAZ produced.
| parameter Model | CUX400-SQ4020 | ||
| X axis travel | 4.0M | ||
| Y axis trave | 2.0M | ||
| Z axis travel | 0-150mm | ||
| Type of machine | Cantilever Type | ||
| Max material thickness | 120mm-150mm | ||
| Control Accuracy | ±0.02mm | ||
| Cutting Accuracy | ±0.1mm | ||
| Max working pressure | 60000 psi (400Mpa) | ||
| Motor Power | 22kw/30kw | ||
| High pressure pump type | intensifier type, 30 HP (Minimum) | ||
| Power | 380 Volt / 3 Phase / 50 Hz | ||
| Cut range material | from metal, steel ,glass ,stone ,granite, ceramic ,marble,foam, plastic even food is well. | ||
We specialized in manufacturing of water jet for 12 years, all products with CE/SGS approved.
Cutting materials: glass, metal, steel, marble, stone, ceramic tile, rubber etc.
Thickness: 0-150mm
SPECIFICATION: normally we have 1.3*1.3, 2.5*1.5, 3.0*2.0, 4.0*2.0,6.0*2.0 or custom tailor.
