Product Details
Place of Origin: | Henan, China | Brand Name: | WEIHUA | Model Number: | JM JK |
Power Source: | Electric | Application: | Other, Cranes, Mine, Construction, Crane | Capacity: | 5~650KN |
Product Description
JM Slow Speed Crane Electric Winch
General description
Low speed electric winch is gear reducer transmission type electric winch.
This series of electric winch is mainly used to pull or lift heavy objects in road and bridge projects, civil construction, mining area, factory, port, marine, e.g, Installation and disassembly of all kinds of large or super large size steel structure and machinery equipments, reinforce concrete, drag ships, the features are orderly wire rope, safe and reliable lifting, speed is usually not more than 12m/min.
In General
1. Cap.: 1-80t
2. Lifting height: customized
3. Lifting speed: single/VVVF
4. Voltage: 220v/380v/400v/415v
5. Push button or cam control or remote control
6. Siemens or Schneider electrical system
7. Current overload protection function, voltage lower protection function.
Control way:
Push button control & Cam control & remote control
Design standards
a. Round strand wire rope GB/T20118-2006
b. Crane design standard GB3811-2011
c. Construction winch testing standards and methods GB6947-1986
Product Dispaly:
JM Series Electric Control Slow Speed Electric Winch | |
| |
JM Series Electric Control Slow Speed Large Tonnage Electric Winch | |
| |
JK Series Electric Control High Speed Electric Winch | |
| |
JKL Series Hand Control High Speed Free Rolling Winch | |
| |
JK-D Series Electric Winch | |
|
Type basic date | Rated load | Rated speed | Rope capacity (m) | Rope diameter | Electric motor type | Electric motor power (KN) | Orm dimension (mm) | Weight (kg) |
---|---|---|---|---|---|---|---|---|
JM10 | 100 | 8 | 170 | Φ30 | YZR200L-6 | 22 | 2090×1475×956 | 3000 |
JM10B | 100 | 9.5 | 250 | Φ30 | YZR200L-6 | 22 | 1705×1598×985 | 3500 |
JM12.5 | 125 | 8 | 300 | Φ34 | YZR225M-6 | 30 | 2880×2200×1550 | 5000 |
JM13.5 | 135 | 0-5 | 290 | Φ28 | YZP225S-8 | 22 | 2990×2363×1650 | 6500 |
JM16 | 160 | 10 | 500 | Φ37 | YZR250M2-6 | 37 | 3750×2400×1850 | 8800 |
JM20 | 200 | 10 | 600 | Φ43 | YZR280S-8 | 45 | 3950×2560×1950 | 9900 |
JM25 | 250 | 9 | 700 | Φ48 | YZR280M-6 | 55 | 4350×2800×2100 | 13500 |
JM32 | 320 | 9 | 700 | Φ56 | YZR315S-8 | 75 | 4500×2850×2100 | 14800 |
JM50 | 500 | 9 | 800 | Φ65 | YZR315M-8 | 90 | 4930×3050×2250 | 19500 |
JM65 | 650 | 10.5 | 3600 | Φ64 | LA8315-8AB | 160 | 5900×4680×3200 | 46000 |
According to your requirements, our products are customized. Please contact us .
After-sales Services
Warranty
WEIHUA grants our clients a twelve-month period or 2000-hour warranty for any products purchased from our company.
Spare Parts
WEIHUA is dedicated to provide our clients with high quality spare parts. With our global distributor network, you are guaranteed with fast deliveries and services, wherever you are.
Installation&Maintenance
WEIHUA is able to provide you with the overall installation of complicated machinery and equipment and inspection of the whole machine, operation equipment.
Training
WEIHUA offers training services to different users. Training programs can be conducted in our factory field, or at the client’s site.
Technical Advice
WEIHUA can also help clients coordinate with trained service personnel to provide you detailed and extensive knowledge about your specific machine.
1. Sales manager cell number is 24hours available.
2. Payment term is flexible.
3. Design the product according to your technical request.
4.Our engineer is willing to help fixing the crane for you.
5. Diversity of products.
6. Delivery on time.
7. Warranty: 12 months.
For more details, please contact us!
This is the overview of our products. For more details, please never hesitate to tell us, we will be pleased to be of further assistance.
