Help CenterRGX P6 Indoor Full Color Led Screen Display Panel, p6 Rental Led Cabinet Quality Choice
Related Products
-
RGX P6 Indoor Full Color Led Screen Display PanelUS$ 900 - 1,200MOQ: 1 Square Meter -
RGX P6 Indoor Full Color Led Video WallUS$ 900 - 1,200MOQ: 1 Square Meter
-
RGX HD P6 Indoor Full Color Led Video ScreenUS$ 900 - 1,200MOQ: 1 Square Meter
-
RGX P7.62 LED MODULE INDOOR FULL COLOR SCREENUS$ 700 - 950MOQ: 1 Square Meter
-
RGX High Definition P7.62 Smd Indoor Full Color Led Display Screen ModuleUS$ 700 - 950MOQ: 1 Square Meter
RGX Software Introduction;
Multi language: English/Spanish/Russia/Inter.char.set…..
All programs are transmitted by compression package, and then decompressed on control card.
Supports animation(swf,gif) , picture, text, clock, temperature, etc.
Text program edit in any language, any font and any size, free adjust
Transparent text and clock program can be edit to cover photo or video
More than 60 effects for text and picture, such as: snow fall, mosaic, slide zebra, fan open and etc.,
With multi-program mode. Stores up to 512 programs to the Led screen.
With hierarchical management of programs in menu type so as to keep clear structure and convenient maintenance.
Supports programs played at the appointed period (for example: week, hour, minute )
1 RGX P6mm slim led video wall display panel screen Specification
Unit Module |
Item: |
RGX LED Parameter |
Model: |
P6mm indoor Full color led Module |
|
Pixel Pitch: |
6 mm |
|
Pixel configuration: |
3in1 (1R1PG1B SMT 3in1) |
|
Module Size: |
192mm * 192mm 384mm * 192mm |
|
Module Resolution: |
32dots(W) * 32dots(H) 64dots(W) * 32dots(H) |
|
Module Thickness: |
14.85 mm |
|
27.15mm(included magnet) | ||
Module Weight: |
0.154 KG and 0.212KG |
|
Package LED mode: |
SMD3528 |
|
Max Power: |
20W |
|
Pixel Density: |
27777 dots / SQM |
|
Driving Method: |
Constant Current Driving |
|
Scan Method: |
1/4 scan or 1/8 scan |
|
Interface Way: |
HUB 75 |
|
Brightness: |
≥ 3500CD /SQM |
|
Unit Cabinet |
Cabinet Size: |
576mm * 576mm (Customize) |
Cabinet Composing: |
9 pcs |
|
Power Supply Mode: |
5V/40A |
|
Cabinet Resolution: |
96dots * 96dots |
|
Optimal Viewing Distance: |
5-60M (according to the big screen size) |
|
Optimal Viewing Angle: |
Horizontal angle: 160 degree; Vertical angle: 120 degree |
|
Environment Temperature: |
Storage: -40 degree `~ +85 degree Work: -20 degree ~ +60 degree |
|
Relative Humidity: |
10% ~ 95% |
|
Power |
Operating Voltage: |
AC:100V~120V AC:220~240V |
Average Power: |
180/SQM |
|
Max Power Consumption: |
≤ 600W/SQM |
|
Current: |
≤ 20mA (single LED) |
|
Control System |
Computer: |
Pentium4 or above P4 or above |
Operate System: |
Win98/2000/NT/XP |
|
Control Mode: |
Synchronization with PC |
|
|
Main Technical Parameter |
Driving Device: |
IC Constant Current Driving |
Refresh Rate: |
≥ 600Hz |
|
Gray/Color: |
RGB each 256 grade, can display 16.7color |
|
MTPF: |
≥ 9000hours |
|
Power Switch: |
RGX Automatic Switch |
|
Display Mode: |
800*6001024*7681280*960 |
2 Shenzhen RGX P6mm indoor full color LED display
P2.5mm P3mm P4mm P5mm P6mm P7.62mm P10mm led display untra slim cabinet
P2.5mm P3mm P4mm P5mm P6mm P7.62mm P10mm led display untra Iron slim cabine
Shenzhen RGX led display :
3 RGX Company photo:
5: Test: Each producing step of P6mm full color led display we had strict test.
7: Installation:
8: indoor led display System:
9: Pack
10: Transportation
11: Our Advantage:
1) Competitive price
2) Professional manufacturer
3) Exquisite quality
a: ISO 9000 and 5S management system
b: Each procedure have special machine and QC to supervise and check
c: From the material purchasing, all have the special Equipment to stakeout
4) Perfect service
a, 2-5years guarantee with free charge, maintain in all life
b, Free training in our company or guide installation and train in customer country or on lone training by long-distance control in internet
Regular training and meeting in each month for all customers, provide strong technology for each customer at the first time
In the end, thank you very much for you time and have good business for you
