Help CenterUFZ-55 Float Type Level Indicator/floating Ball Level Meter
Related Products
-
Input Type Liquid Level Gauge/indicator/transmitterNegotiableMOQ: 1 Set -
UFZ-52 Magnetic Liquid Level Gauge Digital Level Meter With Digital OutputNegotiableMOQ: 1 Set
-
HG-5 Glass Tube Water/liquid Level Gauge,meterNegotiableMOQ: 1 Set
-
USB-L Reflex Level Gauge/glass Level IndicatorUS$ 160 - 560MOQ: 2 Units
-
Magnetic Level Indicator/gaugeNegotiableMOQ: 1 Set
Summary
UFZ-55 Top loaded floating ball level meter is used for measuring all kinds liquid level in the containers that not easy to fit side, especially good for the banks underground.
The alarm and transmitter are available
Types
1.According to the function, it can be divided: the basic type; with the alarm type; with the transmitter type.
2.According to the anti-explosion grade, the alarm and the transmitter can be divided: anti-explosion type and the safe type
The main technology parameters
1. The basic type
(1) Measuring range:500~3000mm
(2) Error:±10mm
(3) Working pressure: ≤ 1.6MPa
(4) Medium temperature:-40~300
(5) Medium density:≥0.7g/cm3
(6) Flange connection:DN150,PN1.6,standard HG20592~20593-97(or other standard)
(7) Meet liquid material: 1Cr18Ni9Ti, 304, 316, Ti
2. The alarm
(1) Alarm error:±5mm
(2) Output form:Often a signal switch
(3) Contact capacity:24V.DC,0.3A
(4) Working life: >105
(5) Power source: 24V.DC
(6) Outlet: M20×1.5(internal thread)
(7) Transmission range:3km
(8) Ambient temperature: -40~60°C
(9) Anti-explosion grade: anti-explosion type and diiBT-D
(10) Degrees of protection provided by enclosure:IP65
(11) Weight: 0.5kg
3. Transmitter
(1) Measuring range: 0~3000mm
(2) Error: ±10mm
(3) Output single:4-20mA.DC
(4) Load impedance:550Ω
(5) Power source:24V.DC;
(6) Outlet:M20×1.5(internal thread)
(7) Ambient temperature:-40~60°C
(8) Anti-explosion grade: dIIBT-4, ibIIBT4
(9) Degrees of protection provided by enclosure:IP65
Shenyang Beixing Meter Manufacture Co., Ltd. was founded in August of 1995. We are located at Shenyang Economic & Technological Development Area and our company covers an area of 18,000sqm. Our company is specialized in manufacturing flow & level measuring instruments, chemical glass products, chemical glass pipes and special glass apparatus. Meanwhile, we also act as an agent of mechanical & electrical products, pressure instruments, chemical reagents, chemical materials, laboratory apparatus & science equipment, contract to design the instrument and meter engineering, chemical industry pipeline & laboratory auxiliary projects, process on given materials and take mechanical manufacturing.
