LZBD glass tube rotameter with digital display,variable area flow meter
General information
The flow meter not only has the original flow meter’s intuitive reading, anti-corrosion, simple structure, but also output a 4~20mA electric signal, which can work with DDZ electric meter, in order to transmits data such as reading, record, totalize, alarming, auto-adjust and anti-explosive. The signal can be sent to computer and internet to achieve choice of multi-functional applications.
LZBD data transmissible flow meter is the ideal flow meter for liquid, gas measurement, control, regulation and totalize. It’s wildly used in chemical, pharmaceuticals, environmental protection, oil and many other industrial departments or research units.
The main technical parameters
1. Accuracy: ±2.5%
2. Maximum working pressure: 0.6Mpa; 0.9MPa; 1MPa
3. Working temperature: 0~120°C
4. Transmitter working environment: Temperature: 0 ~40°C,
Relative humidity: <80%
5. Output signal: 4 ~ 20mA DC
6. Power supply: DC 24V
7. Load resistance: 750Ω
8. Anti-explosive level: EX(ib)cT4 with B902A Zener Barrier
9. Normal Specification: DN10; DN15; DN25;DN40; DN50; DN80; DN100.
Other size is available according to your demand.
10. Measurement range: water: 6~40000L/h air: 0.1~1000m3/h
Structure size
Bore |
A |
B |
C |
D |
L |
H |
DN15 |
¢45 |
¢65 |
¢95 |
4 - ¢14 |
470 |
14 |
DN25 |
¢65 |
¢85 |
¢115 |
4 - ¢14 |
470 |
14 |
DN40 |
¢85 |
¢110 |
¢145 |
4 - ¢18 |
570 |
16 |
DN50 |
¢100 |
¢125 |
¢160 |
4 - ¢18 |
570 |
16 |
DN80 |
¢125 |
¢150 |
¢185 |
4 - ¢18 |
660 |
18 |
DN100 |
¢145 |
¢170 |
¢205 |
4 - ¢18 |
660 |
18 |
Bore |
A |
L |
B |
H |
H1 |
H0 |
D |
L1 |
L2 |
|
Soft Pipe |
Thread |
|||||||||
DN10 |
50 |
244 |
50 |
208 |
18 |
228 |
¢12 |
M12X1 |
77 |
130 |
Shenyang Beixing Meter Manufacture Co., Ltd. was founded in August of 1995. We are located at Shenyang Economic & Technological Development Area and our company covers an area of 18,000sqm. Our company is specialized in manufacturing flow & level measuring instruments, chemical glass products, chemical glass pipes and special glass apparatus. Meanwhile, we also act as an agent of mechanical & electrical products, pressure instruments, chemical reagents, chemical materials, laboratory apparatus & science equipment, contract to design the instrument and meter engineering, chemical industry pipeline & laboratory auxiliary projects, process on given materials and take mechanical manufacturing.
