Summary
QZL mass flow meter is a high accuracy measuring flow meter. It can measure very low flowing speed of medium and high speed flowing up to 200L per minute. The flow meter is able to measure, display reading and output current signal of 4 – 20mA for long distance computer control and alarming system. The equipment solved the problem of measuring low flowing rate. The QZL mass flow meter playing an important part in IC industry, special materials, chemical industry, the petroleum industry, medical, environment protection, etc.
Application
It widely used in gas analyzer, low vacuum control, process control, oxygen supply, anesthesia control apparatus, micro-reactor, capillary measurements, and medical breathing apparatus etc. The QZL mass flow meter is the best flow meter for gaseous mass measuring and controlling in many kinds of industry and research group.
Specification
1.Measuring range available in: 0-30mL/min, 0-100mL/min, 0-200mL/min, 0-1L/min, 0-5L/min, 0-6L/min, 0-10L/min,0-15L/min, 0-20L/min, 0-100L/min, 0-200L/min.
2.Accuracy: ±2%
3.Response circus: 0.5 sec
4.Pressure: 0.1MPa
5.Linear expansion: 2%
6.Environment temperature: 0 ~ 50 °C
7.Input signal: 1 ~ 5V
8.Output signal: 4 -20mA, DC
9.Power supply: 100 – 240V AC/50 – 60Hz
10.Power loss: ≤5W
11.Facial size available in (mm):96x48, 96x96, 160x80
12.Visual reading area available in (mm):92x45, 92x92, 152x76
