Help CenterFlexible Rubber Expansion Joints
US$ 1 - 100
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Material:
Other, Rubber and Carbon steel
Technics:
Forged
Type:
Flange
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO CHINA
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Rubber Expansion Joint Price CompetitiveUS$ 1 - 100MOQ: 5 Pieces -
NBR/EPDM/Neoprene Rubber Expansion JointUS$ 1 - 299MOQ: 5 Pieces
-
Single and Double Sphere Rubber Expansion JointUS$ 1 - 100MOQ: 5 Pieces
-
Schedule 40 Steel PipeUS$ 650 - 1,000MOQ: 5 Tons
-
High Pressure Forged Steel Pipe Fittings SW UnionUS$ 0.1 - 50MOQ: 5 Tons
Material
Other, Rubber and Carbon steel
Technics
Forged
Type
Flange
Place of Origin
Shandong, China
Brand Name
EATHU
Connection
Flange
Shape
Equal
Head Code
Other, Round
Specifications
flexible rubber expansion jointsNBR/EPDM/Neoprene Body
Single and Double sphere
Flange and Union connection
DN25-DN600
flexible rubber expansion joints
Material
| Rubber | EPDM/NBR/Neoprene |
| Carcass | Nylon Cord Fabric |
| Reinforcing wire | Spring Steel wire |
| Flange |
Carbon steel, Zinc Plated DIN2501,ANSI B16.5,JIS etc standard |
| Union |
Malleable iron, zinc plated DIN2999,NPT,BSP etc thread |
Technical information
| Working Pressure | 10 bar | 16bar | 25 bar |
| Burst Pressure | 30 bar | 48bar | 55bar |
| Vaccum | 400 mmHg | 650mmHg | 750mmHg |
| Temperature | EPDM | -10 to 120 degree | |
| NBR | -10 to 82 degree | ||
| Neoprene | -10 to 110 degree | ||
| Medium | air,water,oil,acid,alkali etc | ||
Applicantion
For supplying water, electric power, chemical industry, shipbuilding and so on.
Advantage
good flexibity, noise and vibration reduction, low mass, easy installation and resistance against acid, alkaline, oil and high temperature.
Qingdao Eathu Casting and Forging Co.,ltd
Pipeline System Specialist
Competitive price, High Quality and Super Service, welcome to inquire!
