Help CenterHigh Resolution P3.2mm Concert Touring Custom LED Display
Related Products
-
2x1m Trade Assurance High Brightness P3.9 Stage Rental LED ScreenUS$ 3,930 - 4,210MOQ: 1 Square Meter -
Trade Assurance Outdoor SMD LED Display Panel for StageUS$ 4,110 - 4,130MOQ: 1 Square Meter
-
Newly Designed and High Brightness Outdoor HD Rental LED Display Most PopularUS$ 4,110 - 4,130MOQ: 1 Square Meter
-
High Quality Die-casting Aluminum Cabinet P3.2 Outdoor Rental LED DisplayUS$ 6,160 - 6,360MOQ: 1 Square Meter
-
2016 Hot Sale Outdoor HD Rental LED DisplayUS$ 3,080 - 3,280MOQ: 1 Square Meter
Product Features
|
Lightweight The aluminum die-casting technology makes the single cabinet as light as 8kg, which is convenient for assembly and transportation. Are you planning to move the display after some timer? Make it a rental display!
Seamless connection The aluminum die-casting will have less tolerance , the precision reach ±0.05m so as to achieve seamless assembly. Stronger and better looking compared to normal cabinets.
Modular and easy to maintain There is almost no more ribbon cables for the cabinet and module. Everything connected straight on the PCB hub. Less cables means less possible problems. And no need to disassemble the whole screen for maintenance. Each component can be detached individually for that purpose.
High brightness For our outdoor HD LED Display series (P3.2, P3.9, P4.8, p6.25, P7.8), brightness: approx 5000cd/m² ~ 8000cd/m² (Standard Adjusted). The higher brightness than conventionally spliced screens make the picture more colorful and vivid even in bright environments.
High refresh rate The driving is using the new Taiwan technology for high performance. The chips can generate a speed of > 3840Hz refresh rate to ensure the picture wrinkle-less, line-less and stable.
No ghost effect It is because we use the highest technology of driving chips that also will improve the ghost effect. Ghost effect gives a bad results on led display screens and now be eliminated.
|
High Resolution P3.2mm Concert Touring Custom LED Display
P3.2mm Concert Touring Custom LED Display Specification
| NO. | Iterm | Parameters | ||||
| 1 | Pitch Pixel | 3.2mm | ||||
| 2 | Environment | Outdoor | ||||
| 3 | Viewing Distance | >3.2m | ||||
| 4 | LED Pixel Density | 97656pixel/m² | ||||
| 5 | LED Density | 292968leds/m² | ||||
| 6 | Display Colors | 64 Billion Colors (RGB) | ||||
| 7 | Frequency | >60Hz | ||||
| 8 | Refresh Rate | >3840Hz | ||||
| 9 | Max Consumption | 2958Watt/m² | ||||
| 10 | Avg Consumption | 986Watt/m² | ||||
| 11 | Brightness Estimate | 4053cd/m² | ||||
| 12 | Brightness Adjust | 5000cd/m² (Standard Adjusted) | ||||
| 13 | Viewing Angle | 140°/140° | ||||
| 14 | Life Time | 100000Hours | ||||
| 15 | MTBF | 5000Hours | ||||
| 16 | White Balance | 6500K | ||||
| 17 | Grayscale | 14Bit | ||||
| 18 | Aspect Ratio | 1:1 | ||||
| 19 | Ethernet Cables | CAT 6 | ||||
Rental Aluminum Cabinet
P3.2mm Concert Touring Custom LED Display Cabinet Specification
| NO. | Iterm | Parameters | ||||
| 1 | Cabinet Size | 500(W)mm x 500(H)mm x 85(T)mm | ||||
| 2 | Cabinet Resolution | 156 x 156Pixels | ||||
| 3 | Cabinet M² size | 0.25m² | ||||
| 4 | Module Quantity | 2 x 2 = 4PCS | ||||
| 5 | Max Consumption | 739Watt/Cabinet | ||||
| 6 | Avg Consumption | 246Watt/Cabinet | ||||
| 7 | Coating Color | Black (Standard) | ||||
| 8 | Maintenance | Back Maintenance | ||||
| 9 | Mounting | On a backframe | ||||
| 10 | Series Power Cables | 4 Max Cabinets seriess power connected | ||||
Rental Cabinet Structure
P3.2mm Concert Touring Custom LED Display Module Specification
| NO. | Iterm | Parameters | ||||
| 1 | Pixel Pitch | 3.2mm | ||||
| 2 | LED Type | SMD 2121 | ||||
| 3 | Module Size | 250(W)mm x 250(H)mm | ||||
| 4 | Module Resolution | 78 x 78 Pixels | ||||
| 5 | Pixel Density | 6104Pixels | ||||
| 6 | Module Scan | 13 Scan | ||||
| 7 | LEDs Each Pixel | 3 Pixels | ||||
| 8 | Driving Chip | MY9868SS | ||||
| 9 | LED Module Voltage | 5V | ||||
Connection diagram for general application
Aging Testing
LED display aging test precautions
1. The test content: black and white, red, green, blue monochrome, grayscale gradient, video effects, text effects
2. LED display a white screen test playing time is not less than 24 hours
3. Monochrome and grayscale gradient test not less than 24 hours
4. Video and text effects test not less than 24 hours
Rental LED Display Gallery
Wooden Package (Standard)
Flight Case Package (Optional)
Trade Terms: EXW, CIF, FOB
Payment Terms: T/T, Western Union, PayPal, Escrow, MoneyGram
Payment Condition: TT 100% in advance; TT 50% deposit in advance, 50% balance arranged before shipment
Delivery Time: 10~15 days from receipt of payment in advance
Packing: Standard export wooden box packing
Shipping: By Express, By air, By sea
Company View
Why Choose us?
U-GREAT has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
FAQ
What Pixel of the outdoor led rental display you can provide?
Current we can provide it for P3.2, P3.9, P4.8, P6.25, P7.8, etc. this is our new and hot type outdoor rental led display series. Also we can provide P5, P6, P8 and P10 for your application.
What size of the led display you can provide?
The size of the led display is base on the customers’ need. For our this outdoor HD rental aluminum die-casting cabinet led displays (P3.2, P3.9, P4.8, P6.26, P7.8) the cabinet size are same 500 x 500mm, and the led module sizes are the same 250mm x 250mm. For this, you only need replace the led module next time rather than the whole led display.
Which refresh rate for the led display you can provide?
For our HD outdoor rental led display series, the maximum refresh rate can be achieved more than 3840Hz. Also we can provide the normally refresh rate if you need.
Are there any software updates for the large led display signs?
Yes. We will provide our clients who bought with us a led display all the software-updating necessary and free of charge
What is the warranty of our full color LED display signs?
Normally we will provide customers 2 years warranty and long term technology support and after-service.
