Centrifugal Pumps for Cooking, Fiberline , Chemical preparation and Tank Farm Aera
Welcome to Dubai poultry Livestock Show-S3F10 (2016 AGRE Me)
Agricultural water pump
AC water pump:
Power: 15kW
Voltage: 3-phase 380V AC, 50Hz
Type: multi-stage centrifugal submersible pump
Series: water cooling and reinforced motor suitable for solar power
Max flow: 70m3/hour
Max head: 276m
Outlet: 1.25/1.5/2/2.5/ 3/4 inches
NEMA standard: 96mm
Diving depth: ≤50m
Materials:
Water outlet: 304 stainless steel
Impeller: 304 stainless steel
Pump body: 304 stainless steel
Motor casing: 304 stainless steel
Motor shaft: 304 stainless steel
Screw: 304 stainless steel
Upper guide bearing, thrust bearing base: cast iron, can be updated to be stainless steel with extra cost if needed
Water quality: sand content (weight ratio) in water should not exceed 0.01%, chlorine content should not be over 400mg/L
Max average daily water supply: 400m³@ 5.5KWh/m²/day
Warranty: 18 months, extend to 2-year warranty optional with extra cost
Advantages:up to 15yrs lifespan, working is reliable and stable
Controller and inverter:
Power: 22KW
Input voltage: 330-710V
Output voltage: AC, 3-phase 380V
MPPT voltage:450-600V
Max MPPT efficiency: ≥97%,soft start/stop
Warranty: 2-year, extend to 3-year warranty optional with extra cost
Protections:
Over current, voltage, speed, temperature
Reverse polarity
Dry water/phase failure protection
Advantages: high MPPT efficiency function, GMS remote control, auxiliary diesel power/3 phase AC electricity hybrid power transfer-switch controller, water flow control regulator, soft start/stop
Solar panel reference:
Power: mono/poly, totally about 21kW
Positive tolerance: +0/5W
Products warranty: 10 years
Performance warranty: 90%/10 years, 80%/25 years
Mounting system:
Type: fixed mode/pillar manual tracking/slanting uniaxial tracking
Foundation: concrete pouring
Installation type: 6 pieces/array and vertical
Warranty: 5 years
Material: hot-dip galvanized
Combiner box: N/A
Accessories: PV cables, water pump cables, water level detective sensor, cable sleeves, pipeline, flange, riser pipe
The quantity of accessory materials are based on actual design.
Applications:
Ecological irrigation
Solar drought control
Solar living water supply
Agriculture irrigation
Solar desert control
Solar seawater desalination system
Solar city water landscape
Pasture irrigation
Environment and Ventilation
| 1. Evaporative Cooling Pad |
| 2. Centrifugal Shutter Exhaust Fan |
| 3. Drop Hammer Ventilation Fan |
| 4. Hanging Exhaust Fan |
| 5. Butterfly Cone Fan |
| 6. Coal Burning Steam Boiler Heater |
| 7. Fuel Oil Heater |
| 8. Environmental Control System |
Poultry Raising Equipment
| 9. Broiler Cage System |
| 10.Pan Feeding System |
| 11.Breeder Chain Feeding System |
| 12.Breeder Pan Feeding System |
| 13.Nipple Drinking System |
| 14.Pig Feeding System |
| 15.Foggy System |
| 16.Environmental Control System |
Solar Energy Power
| 17.Solar Street Lights |
| 18.Solar Insecticidal System |
| 19.Solar Photovoltaic Pump |
| 20.Automatic Control System |
Greenhouse Parts
| 21.Automatic Control System |
Water Treatment
| 22.Livestock and Poultry Farm |
Q: What voltages you can do , if you can make special voltages ?
A: Normal standard is 380V for 3phase, 220V for singple.The voltage and herz can be customized as your requirement.For example,400V,240V,60Hz.
Q: How long is the warranty?
A: One year. Brokens parts can be provided free of charge during this period.We use good materials and motors,the fans are hardly broken.
Q: What is the MOQ , can I order a sample for test?
A: MOQ is 10sets, it's for convienence to arrange products. If you need sample for test ,then order large quantity, 1 set for sample is ok,too.
Q: Are you real manufacturer or ..?
A: Yes, we are 100% original manufactuer of exhaust fan.Our factory located at Qingzhou city,Shandong province.Welcome to visit us.As a manufacturer, we have strict control of the material purchase and productions quality. Make sure the goods delivery to you are unwounded and perfect.
Q: How can I pay?
A: We accept TT(Telegraphic transfer) and L/C(Sight letter of credit).30% deposit is needed for TT payment.Balance against the copy of B/L(bill of lading)
Q: I want to use our own brand , is it ok?
A: Of course it's OK , we can make OEM products and also can provide our own brand products , it's all by your request
