Tools PVD Vacuum Coating Machine

Name: Tools PVD Vacuum Coating Machine
Brand: hawk
SKU: 104952879
Availability: InStock

US$ 38,000 - 79,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, Arc Ion Coating Machine, PVD coating production line

Substrate:

Other, glass,ceramic etc

Ningbo Junying Vacuum Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, Arc Ion Coating Machine, PVD coating production line

Substrate Other, glass,ceramic etc

Coating Vacuum Coating

Place of Origin Zhejiang, China

Brand Name hawk

Model Number LCJYD1004

Voltage 380v

Power(W) 55kw

Dimension(L*W*H) 5*4*3M

Weight 5t

Certification CE

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Product Overviews

Tools Plated(PVD) Coating Machine is our company refers to the overseas vanguard technology,

the newest development’s one physical vapor phase deposition (PVD) vacuum coating equipment,

may simultaneously install two to four kind of different fine metal or the alloy target materials, carries

on the monolayer or the multi-layer (nanometer) the membrane plates the system. It’s suitable plate

the coating request in each kind of tool, like the cutting tool, the drill bit, flushes traces has and so on.

Through to the work piece surface in aspect and so on physics, chemistry, machinery, color modifications,

achieves wear-resisting, ultra hard, the self lubrication effect..

Configuration-JYD

Configuration
Model	JYD600	JYD900	JYD1300	JYD1500
Chamber(mm)	Φ600*H800	Φ900*H1200	Φ1300*H1500	Φ1500*H1800
Multi-arc ion	10kw	20kw	30kw	40kw
Power	30kw	35kw	45kw	60kw
characteristic	High-quality stainless steel, double laminated water-cooled, single door with viewing window
Type of power	Multi-arc ion power, DC bias power supply
Pump system	Roots pump+ diffusion pump + mechanical pump + maintain pump+solenoid valve + cylinder
Rotation	Inverter, public switched turn rack,
Heating	High quality heating system, up to 450 ° C
Gas Flowmeter	high-precision gas flow controllers, gas flow and gas flow controller supporting digital instrument can be controlled fixed amount of gas, but also with the process memory
Protection	Electricity, water, gas pressure automatic alarm when missing, diffusion pump, automatic target water alarm reminder
Operating	A key pickup,Semi-automatic or fully automatic operation system, PLC + touch screen
Electrical	World famous brands, Schneider, Omron, Siemens, etc.
Remark	Special requirements can be customized according to customer requirements
