photopolymer plate maker

Specifications

photopolymer plate maker
1,Green Product
2,Samples available
3,Excellent Solid printing performanced
4,High impressions

photopolymer plate maker



Features:
 Green Product, suitable for water base ink
 Optimal hardness and flexibility
 Excellent dot and isolated line reproduction
 Solid printing performance
 High latitude of exposure and processing
 Good ink transfer
 High impression.



Characteristics:

Type	R284
Plate Thickness(mm)	2.84
Durometer (Shore A)	45-48
Recommended Relief Depth (mm)	1.0-1.2
Image Reproduction	2%~95%
Maximum Line, Line/Inch	120
Minimum isolated line	0.175mm (0.0068inch)
Minimum Isolated Dot	0.25mm (0.01inch)
Compatible Ink	Suitable for water and alcohol-based ink, incompatible with oil-based ink, hydrocarbon solvent or the ink containing ethyl acetate of more than 25%
Main Application	Corrugated board, thick board, paper



Technical Specification:

Type	R284
Thickness (mm)	2.84
Back Exposure (seconds)	25-40
Main Exposure (mins)	5-20
Rinsing (mins)	5-7
Drying(hours)	1.5-2
Detackfying (minutes))	8-15
Post Exposure (mins)	5



Dimension:

Type	R284
Thickness(mm)	2.84
Size (mm) (inch)	457×762 (18×30)
	762×1016  (30×40)
	900×1200 (35.4×47.2)
	1067×1524 (42×60)
	1067×2032 (42×80)
	1200×2032 (47.2×80)
	1270×2032 (50×80)

Note:

1) Platemaking conditions: light of 80 watts (11.7mW/cm2 under 365nm), platesetter temperature 24-30 °C.
2) All the above data is depended on our plate-making device. Due to the different requirements of plate-making device, UV lamp power, relief depth and print image, the above recommended time can be changed appropriately. Customers should test on their own device for optimum plate quality.
