Home > Products > Card Punching Machine > SMCPM-A3E plastic card making machine
SMCPM-A3E plastic card making machine
- 50 Set / Sets per Month
- Ningbo or Shanghai
- T/T Credit Card PayPal
Product Details
| Condition: | New | Type: | Hydraulic Cutting Machine | Application: | cut plastic sheet or paper sheet |
| Place of Origin: | Zhejiang, China | Brand Name: | SmartManufacture | Model Number: | SMCPM-A3E |
| Rated Power: | 4KW | Voltage: | 110V or 220V or 380V | Power(W): | 4000 |
| Certification: | CE, ISO9001 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
SMCPM-A3E ID Card Cutting Machine is used to punch A3 or A3+ plastic sheet and paper sheet into cards.
Our card die cutter is widely used for making ID card, VIP card, parking card, poker card, bookmark, bus card.
Automatic adjust sheet position by optical sensors, automatic feed sheet for punching cards.
Servo motor and photographic sensor to make correct feeding position.
Automatic collect punched cards into 3 card stackers and remove the waste sheet.
1.High sensitivity photoelectric sensors read the printing marks, automatic feeding sheets by servo motor, high precision.
2.electric style cutter for cutting motivity, dispense with hydraulic pressure, saving energy and cleanlily, stable motivity.
3.automatic adjust sheet position, automatic transfer the punched cards to card stcker, automatic collect the cards, easy to take out the cards.
4.touch screen frame for man operating, perfect parameter easy and conveniency.
5.automatic running PLC program controlling, when it make a mistake will alarm and stop operating.
| Suitable Material | Plastic and Paper like Teslin, PVC, PET, PETG, ABS and so on |
| Punching Layout | 3*7, 3*8, 3*9, 3*10, 3*11, 3*12 4*8, 4*9, 4*10, 4*11, 4*12 5*5, 5*11, 6*9, 7*8 |
| Punching Die | 3 dies, 4 dies, 5 dies, 6 dies, 7 dies |
| Control Method | PLC and Touch Screen and Servo Motor |
| Cylinder Travel | 18mm |
| Air Source | 0.6Mpa |
| Air Consumption | 100L/minute |
| Power Source | 380V or 220V 50/60Hz |
| Oil Tank | 120L hydraulic oil |
| Work Efficiency | 12000-25000pcs standard card per hour |
| Dimension | 2100mm*1150mm*1850mm |
| Net/Gross Weight | 850KGS/900KGS |
Contact Us
- Ruian Tplast Machine Co., Ltd.
- Contact nameSmart Zou
- Phone0086-130-88669057
- AddressNo. 309, Caizhai East Road, Caizhai Village, Shangwang Street, Ruian
-
